Brother DCP-L5600DN Service Manual

1-10
Confidential
3. SERVICE INFORMATION
Model
DCP-L5500D
DCP-L5500DN
DCP-L5502DN
DCP-L5600DN
DCP-L5602DN
DCP-L5650DN
DCP-L5652DN
DCP-L6600DW
Machine life 300,000 pages or 5 years 600,000 pages or 5 years
Part life (ADF) 50,000 pages or 5 years
Part life (Document
scanner unit)
50,000 pages or 5 years
MTBF 4,000 hours
MTTR 0.5 hours
Maximum monthly
volume
Up to 50,000 pages Up to 125,000 pages
Periodical
maintenance
parts
Fuser unit Up to 200,000 pages
Laser unit Up to 200,000 pages
PF kit 1 Up to 100,000 pages Up to 200,000 pages
PF kit 2 Up to 200,000 pages
PF kit 3 Up to 200,000 pages
PF kit 4 Up to 200,000 pages
PF kit 5 Up to 200,000 pages
PF kit MP Up to 50,000 pages
Specifications are subject to change without notice.
* As for replacement of the periodical maintenance parts, refer to “PERIODICAL
MAINTENANCE” in Chapter 7.
* PF kit 1 to 5 have same parts but their life cycles are different from the marketing strategical
point of view.
(Alarm notification for part replacement sets off according to each model's life cycle.)

Brother DCP-L5600DN Specifications

General

Type	all in one
Color	black/gray, multi
Touch Screen	yes
Display Size	3.7 inches
Tray Capacity	50
Output Tray Capacity	150 sheets
Automatic Document Feeder Capacity	70 sheets
Paper Size	ansi a, legal, executive, a4, a5, a6, folio
Paper Handling	letter, legal, executive, a4, a5, a6, envelopes, custom sizes (3.0-8.5" (w), 5.0-14" (l))
Paper Weight	60 grams per square meter
Printing Method	monochromatic
Color Print Speed	0 pages per minute
Mono Print Speed	42 pages per minute
First Page Print Time	7 seconds
Print Resolution Mono	up to 1200 x 1200
Two-Sided Printing	yes
Maximum Number of Pages Per Month	up to 50, 000
Reduction and Enlargement	no
Photo Printing	no
Scanner Type	flatbed
Scan Resolution	up to 1200 x 1200
Duplex Scan	yes
Max Copies	99
Copier Resolution Mono	up to 1200 x 600
Fax Function	no
Cartridges	brother tn820, brother tn850
Number Of Cartridges	1
Internal Memory	yes
Memory Card	no
Network	wired
Connectivity	usb 2.0, ethernet
Mobile Devices Connection	no

Weight and Dimensions

Depth	16.8 inches
Height	16.8 inches
Width	19.5 inches
Net Weight	37.7 pounds
