Brother DCP-L5600DN Service Manual

2-85
Confidential
4.2.4 No paper is fed from MP tray
<User Check>
• Check that the paper is set in the MP tray deeply.
• Check that the thickness of the paper is 60 to 200 g/m
2
.
• Check that the paper tray is not set as the paper tray.
Step Cause Remedy
1
MP roller holder ASSY
attachment failure
Reattach the MP roller holder ASSY correctly.
2
Connection failure of the paper
feed motor harness
Reconnect the paper feed motor harness.
3
Connection failure of the MP
paper empty sensor harness
Reconnect the MP paper empty sensor
harness.
4
Connection failure of the MP
solenoid harness
Reconnect the MP solenoid harness.
5
MP paper empty actuator
coming off
Reattach the MP paper empty actuator.
6
Connection failure of the
registration front/rear sensor
harness
Reconnect the registration front/rear sensor
harness.
7
Connection failure of the relay
front harness
Reconnect the relay front harness.
8
Connection failure of the HVPS
flat cable
Reconnect the HVPS flat cable.
9
Abrasion of the MP paper pick
up roller
Replace the PF kit MP.
10 MP solenoid failure Replace the MP solenoid.
11
MP paper empty sensor failure Replace the MP paper empty sensor PCB
ASSY.
12
Registration front/rear sensor
PCB failure
Replace the registration front/rear sensor PCB
ASSY.
13 Paper feed motor failure Replace the paper feed motor.
14 Damaged fuser unit Replace the fuser unit.
15 Relay front PCB failure Replace the relay front PCB ASSY.
16
High-voltage power supply PCB
failure
Replace the high-voltage power supply PCB
ASSY.
17 Main PCB failure Replace the main PCB ASSY.

Brother DCP-L5600DN Specifications

General

Type	all in one
Color	black/gray, multi
Touch Screen	yes
Display Size	3.7 inches
Tray Capacity	50
Output Tray Capacity	150 sheets
Automatic Document Feeder Capacity	70 sheets
Paper Size	ansi a, legal, executive, a4, a5, a6, folio
Paper Handling	letter, legal, executive, a4, a5, a6, envelopes, custom sizes (3.0-8.5" (w), 5.0-14" (l))
Paper Weight	60 grams per square meter
Printing Method	monochromatic
Color Print Speed	0 pages per minute
Mono Print Speed	42 pages per minute
First Page Print Time	7 seconds
Print Resolution Mono	up to 1200 x 1200
Two-Sided Printing	yes
Maximum Number of Pages Per Month	up to 50, 000
Reduction and Enlargement	no
Photo Printing	no
Scanner Type	flatbed
Scan Resolution	up to 1200 x 1200
Duplex Scan	yes
Max Copies	99
Copier Resolution Mono	up to 1200 x 600
Fax Function	no
Cartridges	brother tn820, brother tn850
Number Of Cartridges	1
Internal Memory	yes
Memory Card	no
Network	wired
Connectivity	usb 2.0, ethernet
Mobile Devices Connection	no

Weight and Dimensions

Depth	16.8 inches
Height	16.8 inches
Width	19.5 inches
Net Weight	37.7 pounds
