Brother DCP-L5600DN Service Manual

2-39
Confidential
 Error code 0300
Cannot detect the lock signal of the polygon motor for the laser unit (second time).
Error code 0305
Cannot detect the lock signal of the polygon motor for the laser unit (first time).
Error code 0401
Cannot detect the synchronized signal of the polygon motor for the laser unit (second time).
Error code 0405
Cannot detect the synchronized signal of the polygon motor for the laser unit (first time).
Step Cause Remedy
1
Connection failure of the laser
unit flat cable
Reconnect the laser unit flat cable.
2 Laser unit flat cable failure Replace the laser unit flat cable.
3 Laser unit failure Replace the laser unit.
4 Main PCB failure Replace the main PCB ASSY.

Brother DCP-L5600DN Specifications

General

Type	all in one
Color	black/gray, multi
Touch Screen	yes
Display Size	3.7 inches
Tray Capacity	50
Output Tray Capacity	150 sheets
Automatic Document Feeder Capacity	70 sheets
Paper Size	ansi a, legal, executive, a4, a5, a6, folio
Paper Handling	letter, legal, executive, a4, a5, a6, envelopes, custom sizes (3.0-8.5" (w), 5.0-14" (l))
Paper Weight	60 grams per square meter
Printing Method	monochromatic
Color Print Speed	0 pages per minute
Mono Print Speed	42 pages per minute
First Page Print Time	7 seconds
Print Resolution Mono	up to 1200 x 1200
Two-Sided Printing	yes
Maximum Number of Pages Per Month	up to 50, 000
Reduction and Enlargement	no
Photo Printing	no
Scanner Type	flatbed
Scan Resolution	up to 1200 x 1200
Duplex Scan	yes
Max Copies	99
Copier Resolution Mono	up to 1200 x 600
Fax Function	no
Cartridges	brother tn820, brother tn850
Number Of Cartridges	1
Internal Memory	yes
Memory Card	no
Network	wired
Connectivity	usb 2.0, ethernet
Mobile Devices Connection	no

Weight and Dimensions

Depth	16.8 inches
Height	16.8 inches
Width	19.5 inches
Net Weight	37.7 pounds
