Brother DCP-L5600DN Service Manual

2-72
Confidential
 Error code 9701
A tray set to duplex printing-incompatible size was specified in duplex printing.
Error code 9702
When printing from paper tray 1, a paper size not supported for paper tray 1 was specified
from the driver.
Error code 9703
When printing from paper tray 2, a paper size not supported for paper tray 2 was specified
from the driver.
Error code 9704
When printing from paper tray 3, a paper size not supported for paper tray 3 was specified
from the driver.
Error code 9705
When printing from paper tray 4, a paper size not supported for paper tray 4 was specified
from the driver.
Error code 9706
When printing from paper tray 5, a paper size not supported for paper tray 5 was specified
from the driver.
 Error code 9B03
Only T2 tray is set for A4 / Letter / Legal / Folio but T2 is set as "Skip Tray".
Error code 9B04
Only T3 tray is set for A4 / Letter / Legal / Folio but T3 is set as "Skip Tray".
Error code 9B05
Only T4 tray is set for A4 / Letter / Legal / Folio but T4 is set as "Skip Tray".
Error code 9B06
Only T5 tray is set for A4 / Letter / Legal / Folio but T5 is set as "Skip Tray".
<User Check>
• Select the specified paper size in the driver and set paper with the same size to the
specified paper tray.
Step Cause Remedy
1 Main PCB failure Replace the main PCB ASSY.
<User Check>
• Check the paper or Skip Tray setting.
Step Cause Remedy
1 Main PCB failure Replace the main PCB ASSY.

Brother DCP-L5600DN Specifications

General

Type	all in one
Color	black/gray, multi
Touch Screen	yes
Display Size	3.7 inches
Tray Capacity	50
Output Tray Capacity	150 sheets
Automatic Document Feeder Capacity	70 sheets
Paper Size	ansi a, legal, executive, a4, a5, a6, folio
Paper Handling	letter, legal, executive, a4, a5, a6, envelopes, custom sizes (3.0-8.5" (w), 5.0-14" (l))
Paper Weight	60 grams per square meter
Printing Method	monochromatic
Color Print Speed	0 pages per minute
Mono Print Speed	42 pages per minute
First Page Print Time	7 seconds
Print Resolution Mono	up to 1200 x 1200
Two-Sided Printing	yes
Maximum Number of Pages Per Month	up to 50, 000
Reduction and Enlargement	no
Photo Printing	no
Scanner Type	flatbed
Scan Resolution	up to 1200 x 1200
Duplex Scan	yes
Max Copies	99
Copier Resolution Mono	up to 1200 x 600
Fax Function	no
Cartridges	brother tn820, brother tn850
Number Of Cartridges	1
Internal Memory	yes
Memory Card	no
Network	wired
Connectivity	usb 2.0, ethernet
Mobile Devices Connection	no

Weight and Dimensions

Depth	16.8 inches
Height	16.8 inches
Width	19.5 inches
Net Weight	37.7 pounds
