Brother DCP-L5600DN Service Manual

2-71
Confidential
 Error code 930A
Paper ran out during Fax / List continuous printing.
 Error code 9400
Firmware version of the main PCB is older than that of the TT and LT.
<User Check>
• Set paper in the appropriate paper tray.
• Install the latest main firmware.
Step Cause Remedy
1
A paper empty actuator caught in
some sections of the machine
*1
Reattach the appropriate paper empty actuator.
*1
2
A paper feed actuator caught in
some sections of the machine
*2
Reattach the appropriate paper feed actuator.
*2
3
Connection failure of a paper
feed sensor harness
*2
Reconnect the appropriate paper feed sensor
harness.
*2
4
Connection failure of the HVPS
flat cable
*2
Reconnect the HVPS flat cable.
*2
5
Connection failure of the LT
control PCB harness
*2
Reconnect the LT control PCB harness.
*2
6
A paper empty sensor PCB
failure
*1
Replace the appropriate paper empty sensor
PCB ASSY.
*1
7
A paper feed sensor PCB failure
*2
Replace the appropriate paper feed sensor
PCB ASSY.
*2
8 LT control PCB failure Replace the LT control PCB.
9
High-voltage power supply PCB
failure
*2
Replace the high-voltage power supply PCB.
*2
10 A TT relay PCB failure
*1
Replace the TT relay PCB.
*1
11 TT control PCB failure
*1
Replace the TT control PCB.
*1
12
Low-voltage power supply PCB
failure
*2
Replace the Low-voltage power supply PCB
ASSY.
*2
13 Main PCB failure Replace the main PCB ASSY.
Note:
Only for when each tray above is set for A4 / Letter / Legal / Folio.
*1
Models with 520-sheet only
*2
Models with 250-sheet only
<User Check>
• Install the latest main firmware.
Step Cause Remedy
1
Main firmware version and
firmware version of the TT and
LT do not match
Install the latest main firmware.

Brother DCP-L5600DN Specifications

General

Type	all in one
Color	black/gray, multi
Touch Screen	yes
Display Size	3.7 inches
Tray Capacity	50
Output Tray Capacity	150 sheets
Automatic Document Feeder Capacity	70 sheets
Paper Size	ansi a, legal, executive, a4, a5, a6, folio
Paper Handling	letter, legal, executive, a4, a5, a6, envelopes, custom sizes (3.0-8.5" (w), 5.0-14" (l))
Paper Weight	60 grams per square meter
Printing Method	monochromatic
Color Print Speed	0 pages per minute
Mono Print Speed	42 pages per minute
First Page Print Time	7 seconds
Print Resolution Mono	up to 1200 x 1200
Two-Sided Printing	yes
Maximum Number of Pages Per Month	up to 50, 000
Reduction and Enlargement	no
Photo Printing	no
Scanner Type	flatbed
Scan Resolution	up to 1200 x 1200
Duplex Scan	yes
Max Copies	99
Copier Resolution Mono	up to 1200 x 600
Fax Function	no
Cartridges	brother tn820, brother tn850
Number Of Cartridges	1
Internal Memory	yes
Memory Card	no
Network	wired
Connectivity	usb 2.0, ethernet
Mobile Devices Connection	no

Weight and Dimensions

Depth	16.8 inches
Height	16.8 inches
Width	19.5 inches
Net Weight	37.7 pounds
