Brother DCP-L5600DN Service Manual

2-51
Confidential
 Error code 7000
The eject sensor does not detect paper pass after the registration rear sensor detected the
paper pass.
 Error code 7100
The eject sensor remains ON (paper pass detected) even after the registration rear sensor
detected the end of paper pass.
<User Check>
• Remove the jammed paper.
• Replace the drum unit with a new one.
Step Cause Remedy
1
Foreign object inside the
machine
Remove the foreign object.
2
Connection failure of the eject
sensor harness
Reconnect the eject sensor harness.
3
Eject actuator coming off or
caught in some sections of the
machine
Reattach the eject actuator.
4 Fuser cover attachment failure Reattach the fuser cover.
5 Eject sensor failure Replace the eject sensor PCB ASSY.
6
high-voltage power supply PCB
failure
Replace the high-voltage power supply PCB
ASSY.
7 Fuser unit failure Replace the fuser unit.
8
Damaged fuser gears or drum
gears
Replace the main frame L ASSY.
9 Main PCB failure Replace the main PCB ASSY.
<User Check>
• Remove the jammed paper.
• Check if the back cover is open during duplex printing.
Step Cause Remedy
1
Foreign object in the rear of the
machine
Remove the foreign object.
2
Eject actuator caught in some
sections of the machine
Reattach the eject actuator.
3 Fuser cover attachment failure Reattach the fuser cover.
4 Eject sensor failure Replace the eject sensor PCB ASSY.
5
high-voltage power supply PCB
failure
Replace the high-voltage power supply PCB
ASSY.
6 Fuser cover failure Replace the fuser cover.
7
Damaged eject roller 1 drive
gears
Replace the main frame L ASSY.
8 Main PCB failure Replace the main PCB ASSY.

Brother DCP-L5600DN Specifications

General

Type	all in one
Color	black/gray, multi
Touch Screen	yes
Display Size	3.7 inches
Tray Capacity	50
Output Tray Capacity	150 sheets
Automatic Document Feeder Capacity	70 sheets
Paper Size	ansi a, legal, executive, a4, a5, a6, folio
Paper Handling	letter, legal, executive, a4, a5, a6, envelopes, custom sizes (3.0-8.5" (w), 5.0-14" (l))
Paper Weight	60 grams per square meter
Printing Method	monochromatic
Color Print Speed	0 pages per minute
Mono Print Speed	42 pages per minute
First Page Print Time	7 seconds
Print Resolution Mono	up to 1200 x 1200
Two-Sided Printing	yes
Maximum Number of Pages Per Month	up to 50, 000
Reduction and Enlargement	no
Photo Printing	no
Scanner Type	flatbed
Scan Resolution	up to 1200 x 1200
Duplex Scan	yes
Max Copies	99
Copier Resolution Mono	up to 1200 x 600
Fax Function	no
Cartridges	brother tn820, brother tn850
Number Of Cartridges	1
Internal Memory	yes
Memory Card	no
Network	wired
Connectivity	usb 2.0, ethernet
Mobile Devices Connection	no

Weight and Dimensions

Depth	16.8 inches
Height	16.8 inches
Width	19.5 inches
Net Weight	37.7 pounds
