Brother DCP-L5600DN Service Manual

2-52
Confidential
 Error code 7200
When feeding from the MP tray, the registration rear sensor does not detect paper pass
within the specified time after the registration front sensor detected paper pass.
<User Check>
• Remove the jammed paper.
• Add the paper properly using the MP tray paper guide.
• Close the front cover correctly.
Step Cause Remedy
1
Foreign object in the front of the
machine
Remove the foreign object.
2
Registration rear actuator
coming off or caught in some
sections of the machine
Reattach the registration rear actuator.
3
Connection failure of the
registration front/rear sensor
harness
Reconnect the registration front/rear sensor
harness.
4
Connection failure of the
registration clutch harness
Reconnect the registration clutch harness.
5
MP feed frame attachment
failure
Reattach the MP feed frame.
6
Registration rear sensor failure Replace the registration front/rear sensor PCB
ASSY.
7 Registration clutch failure Replace the registration clutch.
8
high-voltage power supply PCB
failure
Replace the high-voltage power supply PCB
ASSY.
9
Damaged gears in the paper
feeding system
Replace the main frame L ASSY.
10 Main PCB failure Replace the main PCB ASSY.

Brother DCP-L5600DN Specifications

General

Type	all in one
Color	black/gray, multi
Touch Screen	yes
Display Size	3.7 inches
Tray Capacity	50
Output Tray Capacity	150 sheets
Automatic Document Feeder Capacity	70 sheets
Paper Size	ansi a, legal, executive, a4, a5, a6, folio
Paper Handling	letter, legal, executive, a4, a5, a6, envelopes, custom sizes (3.0-8.5" (w), 5.0-14" (l))
Paper Weight	60 grams per square meter
Printing Method	monochromatic
Color Print Speed	0 pages per minute
Mono Print Speed	42 pages per minute
First Page Print Time	7 seconds
Print Resolution Mono	up to 1200 x 1200
Two-Sided Printing	yes
Maximum Number of Pages Per Month	up to 50, 000
Reduction and Enlargement	no
Photo Printing	no
Scanner Type	flatbed
Scan Resolution	up to 1200 x 1200
Duplex Scan	yes
Max Copies	99
Copier Resolution Mono	up to 1200 x 600
Fax Function	no
Cartridges	brother tn820, brother tn850
Number Of Cartridges	1
Internal Memory	yes
Memory Card	no
Network	wired
Connectivity	usb 2.0, ethernet
Mobile Devices Connection	no

Weight and Dimensions

Depth	16.8 inches
Height	16.8 inches
Width	19.5 inches
Net Weight	37.7 pounds
