Brother DCP-L5600DN Service Manual

2-23
Confidential
Jam Rear Open the Back Cover
and remove the
jammed paper.
The eject sensor remains ON
(paper pass detected) even after
the registration rear sensor
detected the end of paper pass.
7100 2-51
Jam Tray1 Remove the jammed
paper from Tray 1.
When printing from the paper tray 1,
the registration front sensor does
not detect paper pass within the
specified time after the paper feed
sensor detected paper pass.
7302 2-53
Jam Tray2 Remove the jammed
paper from Tray 2.
When printing from the paper tray 2,
the registration front sensor or the
T2TT jam sensor does not detect
paper pass within the specified time
after the T2(LT or TT) paper feed
sensor detected paper pass.
7402 2-55
Jam Tray3 Remove the jammed
paper from Tray 3.
When printing from the paper tray 3,
the registration front sensor or the
T2/T3TT jam sensor does not detect
paper pass within the specified time
after the T3(LT or TT) paper feed
sensor detected paper pass.
7502 2-57
Jam Tray4 Remove the jammed
paper from Tray 4.
When printing from the paper tray 4,
the registration front sensor or the
T2/T3/T4TT jam sensor does not
detect paper pass within the
specified time after the T4(LT or TT)
paper feed sensor detected paper
pass.
7602 2-59
Jam Tray5 Remove the jammed
paper from Tray 5.
When printing from the paper tray 5,
the registration front sensor or the
T2/T3/T4/T5TT jam sensor does not
detect paper pass within the
specified time after the T5TT paper
feed sensor detected paper pass.
7702 2-61
Error message
Description
Error
codes
Refer
to:
First line Second line

Brother DCP-L5600DN Specifications

General

Type	all in one
Color	black/gray, multi
Touch Screen	yes
Display Size	3.7 inches
Tray Capacity	50
Output Tray Capacity	150 sheets
Automatic Document Feeder Capacity	70 sheets
Paper Size	ansi a, legal, executive, a4, a5, a6, folio
Paper Handling	letter, legal, executive, a4, a5, a6, envelopes, custom sizes (3.0-8.5" (w), 5.0-14" (l))
Paper Weight	60 grams per square meter
Printing Method	monochromatic
Color Print Speed	0 pages per minute
Mono Print Speed	42 pages per minute
First Page Print Time	7 seconds
Print Resolution Mono	up to 1200 x 1200
Two-Sided Printing	yes
Maximum Number of Pages Per Month	up to 50, 000
Reduction and Enlargement	no
Photo Printing	no
Scanner Type	flatbed
Scan Resolution	up to 1200 x 1200
Duplex Scan	yes
Max Copies	99
Copier Resolution Mono	up to 1200 x 600
Fax Function	no
Cartridges	brother tn820, brother tn850
Number Of Cartridges	1
Internal Memory	yes
Memory Card	no
Network	wired
Connectivity	usb 2.0, ethernet
Mobile Devices Connection	no

Weight and Dimensions

Depth	16.8 inches
Height	16.8 inches
Width	19.5 inches
Net Weight	37.7 pounds
