Brother DCP-L5600DN Service Manual

2-79
Confidential
 Error code C700
There is insufficient memory to expand PC print data.
 Error code C800
The memory size allotted for Secure Print was exceeded when saving Secure Print data.
 Error code D100
An error occurred while initializing the modem.
 Error code D200
Detected that the modem PCB is not connected.
 Error code D800
An error occurred while initializing the touch panel.
<User Check>
• Print the print data stored in the memory.
• Divide the print data and print them separately.
Step Cause Remedy
1 Main PCB failure Replace the main PCB ASSY.
<User Check>
• Print the print data stored in the memory.
• Divide the print data and print them separately.
Step Cause Remedy
1 Main PCB failure Replace the main PCB ASSY.
Step Cause Remedy
1
Connection failure of the
modem flat cable
Reconnect the modem flat cable.
2 Modem PCB failure Replace the modem PCB ASSY.
3 Main PCB failure Replace the main PCB ASSY.
Step Cause Remedy
1 Modem PCB failure Replace the modem PCB ASSY.
2 Main PCB failure Replace the main PCB ASSY.
Step Cause Remedy
1
Panel firmware version and
main firmware version do not
match
Install the latest main firmware.
2
Connection failure of the panel
flat cable
Reconnect the panel flat cable.
3 LCD relay PCB failure Replace the LCD panel ASSY.
4 Main PCB failure Replace the main PCB ASSY.

Brother DCP-L5600DN Specifications

General

Type	all in one
Color	black/gray, multi
Touch Screen	yes
Display Size	3.7 inches
Tray Capacity	50
Output Tray Capacity	150 sheets
Automatic Document Feeder Capacity	70 sheets
Paper Size	ansi a, legal, executive, a4, a5, a6, folio
Paper Handling	letter, legal, executive, a4, a5, a6, envelopes, custom sizes (3.0-8.5" (w), 5.0-14" (l))
Paper Weight	60 grams per square meter
Printing Method	monochromatic
Color Print Speed	0 pages per minute
Mono Print Speed	42 pages per minute
First Page Print Time	7 seconds
Print Resolution Mono	up to 1200 x 1200
Two-Sided Printing	yes
Maximum Number of Pages Per Month	up to 50, 000
Reduction and Enlargement	no
Photo Printing	no
Scanner Type	flatbed
Scan Resolution	up to 1200 x 1200
Duplex Scan	yes
Max Copies	99
Copier Resolution Mono	up to 1200 x 600
Fax Function	no
Cartridges	brother tn820, brother tn850
Number Of Cartridges	1
Internal Memory	yes
Memory Card	no
Network	wired
Connectivity	usb 2.0, ethernet
Mobile Devices Connection	no

Weight and Dimensions

Depth	16.8 inches
Height	16.8 inches
Width	19.5 inches
Net Weight	37.7 pounds
