Brother DCP-L5600DN Service Manual

2-92
Confidential
 Paper jams in MP tray
<User Check>
• Check that the paper is set in the MP tray correctly.
• Flip over the paper in the MP tray or rotate the paper 180°.
• Adjust the paper guide according to the paper size.
• Check that the thickness of the paper is 60 to 200 g/m
2
.
• Flip through the paper and reset it in the MP tray.
Step Cause Remedy
1
Foreign object around the MP
tray
Remove the foreign object.
2
Connection failure of the
registration front/rear sensor
harness
Reconnect the registration front/rear sensor
harness.
3
Registration front actuator
coming off
Reattach the registration front actuator.
4
Connection failure of the
registration clutch harness
Reconnect the registration clutch harness.
5
Connection failure of the HVPS
flat cable
Reconnect the HVPS flat cable.
6
Connection failure of the relay
front harness
Reconnect the relay front harness.
7
Registration front sensor failure Replace the registration front/rear sensor PCB
ASSY.
8 Registration clutch failure Replace the registration clutch.
9 Paper feed motor failure Replace the paper feed motor.
10 Relay front PCB failure Replace the relay front PCB ASSY.
11
High-voltage power supply PCB
failure
Replace the high-voltage power supply PCB
ASSY.
12
Damaged gears in the paper
feeding system
Replace the main frame L ASSY.
13 Damaged fuser unit Replace the fuser unit.
14 Main PCB failure Replace the main PCB ASSY.

Brother DCP-L5600DN Specifications

General

Type	all in one
Color	black/gray, multi
Touch Screen	yes
Display Size	3.7 inches
Tray Capacity	50
Output Tray Capacity	150 sheets
Automatic Document Feeder Capacity	70 sheets
Paper Size	ansi a, legal, executive, a4, a5, a6, folio
Paper Handling	letter, legal, executive, a4, a5, a6, envelopes, custom sizes (3.0-8.5" (w), 5.0-14" (l))
Paper Weight	60 grams per square meter
Printing Method	monochromatic
Color Print Speed	0 pages per minute
Mono Print Speed	42 pages per minute
First Page Print Time	7 seconds
Print Resolution Mono	up to 1200 x 1200
Two-Sided Printing	yes
Maximum Number of Pages Per Month	up to 50, 000
Reduction and Enlargement	no
Photo Printing	no
Scanner Type	flatbed
Scan Resolution	up to 1200 x 1200
Duplex Scan	yes
Max Copies	99
Copier Resolution Mono	up to 1200 x 600
Fax Function	no
Cartridges	brother tn820, brother tn850
Number Of Cartridges	1
Internal Memory	yes
Memory Card	no
Network	wired
Connectivity	usb 2.0, ethernet
Mobile Devices Connection	no

Weight and Dimensions

Depth	16.8 inches
Height	16.8 inches
Width	19.5 inches
Net Weight	37.7 pounds
