Brother DCP-L5600DN Service Manual

3-10
Confidential
<Layout view>
Fig. 3-10
<Development view>
Fig. 3-11
<Name of gears>
* These parts are subject to change without notice.
Note:
• When handling gears, make sure that frame L faces up. Otherwise all gears come off.
9 LY4394 MP sector gear 53/57 15 LY4451 DX gear 27/19
10 LY4336 MP drive gear 18 16 LY4450 Fuser drive gear 39
11 D004PV Gear 39/17 PP 17 D0004F Gear 23/40R fuser
12 LY4403 T1 idle gear 37 18 LY4449 Fuser pendulum gear 25
13 LY4398 LT drive gear 29 19 D0004S Gear 22L/33L fuser
14 D0041S T1 gear 19 42
1010
1616
1919
1717
1212
1414
1313
1111
1515
1818
9
10
16
19
17
12
14
13
11
18
9
15
16
16
19
19
11
11
9
9
10
10
12
12
15
15
18
18
17
17
13
13
14
14
16
19
11
9
10
12
15
18
17
13
14

Brother DCP-L5600DN Specifications

General

Type	all in one
Color	black/gray, multi
Touch Screen	yes
Display Size	3.7 inches
Tray Capacity	50
Output Tray Capacity	150 sheets
Automatic Document Feeder Capacity	70 sheets
Paper Size	ansi a, legal, executive, a4, a5, a6, folio
Paper Handling	letter, legal, executive, a4, a5, a6, envelopes, custom sizes (3.0-8.5" (w), 5.0-14" (l))
Paper Weight	60 grams per square meter
Printing Method	monochromatic
Color Print Speed	0 pages per minute
Mono Print Speed	42 pages per minute
First Page Print Time	7 seconds
Print Resolution Mono	up to 1200 x 1200
Two-Sided Printing	yes
Maximum Number of Pages Per Month	up to 50, 000
Reduction and Enlargement	no
Photo Printing	no
Scanner Type	flatbed
Scan Resolution	up to 1200 x 1200
Duplex Scan	yes
Max Copies	99
Copier Resolution Mono	up to 1200 x 600
Fax Function	no
Cartridges	brother tn820, brother tn850
Number Of Cartridges	1
Internal Memory	yes
Memory Card	no
Network	wired
Connectivity	usb 2.0, ethernet
Mobile Devices Connection	no

Weight and Dimensions

Depth	16.8 inches
Height	16.8 inches
Width	19.5 inches
Net Weight	37.7 pounds
