Brother DCP-L5600DN Service Manual

1-7
Confidential
Model MFC-L6750DW MFC-L6800DW MFC-L6900DW MFC-L6902DW
Warm-up
time
From Sleep
mode
Less than 5.7 sec. at 73.4F / 50%RH (23°C / 50%RH) for the U.S.A./
Brazil
Less than 4.7 sec. at 73.4F / 50%RH (23°C / 50%RH) except for the
U.S.A./Brazil
From Power
OFF
 ON
Less than 27 sec. at 73.4F / 50%RH (23°C / 50%RH)
First print
time
From Ready
mode
Less than 7.5 secs at 73.4F (23°C)
From Sleep
mode
Less than 13.2 secs at 73.4F (23°C) for the U.S.A./Brazil
Less than 12.2 secs at 73.4F (23°C) except for the U.S.A./Brazil
Printing speed
(A4/Letter)
Up to 46/48 ppm
(Quiet Mode: Up to 25/26 ppm)
Up to 50/52 ppm
(Quiet Mode: Up to 25/26 ppm)
CPU Cortex-A9
800 MHz
Backup clock Up to 60 hours
Dimensions
(W x D x H)
Carton size 599 x 526 x 762 mm
(23.6 x 20.7
x 30.0 inch)
599 x 526 x 659 mm
(23.6 x 20.7 x
25.9 inch) except
for Italy-CONSIP
599 x 526 x 762 mm
(23.6 x 20.7
x 30.0 inch)
for Italy-CONSIP
599 x 526 x 762 mm
(23.6 x 20.7 x 30.0 inch) except for Oceania
599 x 526 x 659 mm
(23.6 x 20.7 x 25.9 inch) for Oceania
Machine
size
495 x 427 x 518 mm
(19.5 x 16.8 x 20.4 inch)
Weights
with carton 23.3 kg / 51.4 lb 22.6 kg / 49.8 lb
(for the U.S.A.)
22.9 kg / 50.4 lb
(for Europe except
Italy-CONSIP)
23.5 kg / 51.8 lb
(for Italy-CONSIP)
23.5 kg / 51.8 lb
(for the U.S.A.)
23.4 kg / 51.6 lb
(for Latin America)
23.8 kg / 52.4 lb
(for Europe)
22.5 kg / 49.7 lb
(for Oceania)
23.7 kg / 52.3 lb
(for Asia)
23.4 kg / 51.6 lb
without
carton,
with toner/
drum
18.8 kg / 41.4 lb 18.8 kg / 41.5 lb
(for the U.S.A.)
18.9 kg / 41.6 lb
(for Europe except
Italy-CONSIP)
19.0 kg / 41.9 lb
(for Italy-CONSIP)
19.0 kg / 41.9 lb
(for the U.S.A./
Latin America)
19.0 kg / 42.0 lb
(for Europe)
18.9 kg / 41.6 lb
(for Oceania)
19.1 kg / 42.2 lb
(for Asia)
19.0 kg / 41.9 lb
without
carton and
toner/drum
17.0 kg / 37.5 lb 17.2 kg / 37.9 lb
Specifications are subject to change without notice.

Brother DCP-L5600DN Specifications

General

Type	all in one
Color	black/gray, multi
Touch Screen	yes
Display Size	3.7 inches
Tray Capacity	50
Output Tray Capacity	150 sheets
Automatic Document Feeder Capacity	70 sheets
Paper Size	ansi a, legal, executive, a4, a5, a6, folio
Paper Handling	letter, legal, executive, a4, a5, a6, envelopes, custom sizes (3.0-8.5" (w), 5.0-14" (l))
Paper Weight	60 grams per square meter
Printing Method	monochromatic
Color Print Speed	0 pages per minute
Mono Print Speed	42 pages per minute
First Page Print Time	7 seconds
Print Resolution Mono	up to 1200 x 1200
Two-Sided Printing	yes
Maximum Number of Pages Per Month	up to 50, 000
Reduction and Enlargement	no
Photo Printing	no
Scanner Type	flatbed
Scan Resolution	up to 1200 x 1200
Duplex Scan	yes
Max Copies	99
Copier Resolution Mono	up to 1200 x 600
Fax Function	no
Cartridges	brother tn820, brother tn850
Number Of Cartridges	1
Internal Memory	yes
Memory Card	no
Network	wired
Connectivity	usb 2.0, ethernet
Mobile Devices Connection	no

Weight and Dimensions

Depth	16.8 inches
Height	16.8 inches
Width	19.5 inches
Net Weight	37.7 pounds
