Brother DCP-L5600DN Service Manual

1-14
Confidential
Model
MFC-8530DN
MFC-8535DN
MFC-8540DN
MFC-L5700DW
MFC-L5702DW
MFC-L5750DW
MFC-L5755DW
MFC-L5800DW
MFC-L5802DW
MFC-L5900DW
MFC-L5902DW
MFC-L6700DW
MFC-L6702DW
MFC-L6750DW
MFC-L6800DW
MFC-L6900DW
MFC-L6902DW
Toner
cartridge
Starter
Toner
*1
Approx.
3,000
pages
Approx.
2,000
pages
(except for
Asia, MFC-
L5702DW)
Approx.
8,000
pages
(for Asia,
MFC-
L5702DW)
Approx.
3,000
pages
(except for
Asia, MFC-
L5802DW /
L5902DW)
Approx.
8,000
pages
(for Asia,
MFC-
L5802DW /
L5902DW)
Approx.
3,000
pages
(except for
Asia, MFC-
L6702DW)
Approx.
8,000
pages
(for Asia,
MFC-
L6702DW)
Approx.
8,000
pages
(except for
MFC-
L6750DW)
Approx.
12,000
pages
(for MFC-
L6750DW)
Approx.
8,000 pages
(for Oceania)
Approx.
12,000 pages
(except for
Singapore,
Asia, Gulf,
Korea,
Oceania,
MFC-
L6902DW)
20,000 pages
(for
Singapore,
Asia, Gulf,
Korea, MFC-
L6902DW)
Standard
Toner
Approx. 3,000 pages
High
Capacity
Toner
Approx. 8,000 pages
Super
High
Capacity
Toner
Approx.
12,000
pages
Approx.
12,000
pages
(for Asia,
MFC-
L5702DW)
N/A
(except for
Asia,
MFC-
L5702DW)
Approx.
12,000
pages
(except for
the U.S.A.)
N/A
(for the
U.S.A.)
Approx. 12,000 pages
Ultra High
Capacity
Toner
N/A Approx.
20,000
pages
When printing A4/Letter size one sided pages in accordance with ISO/IEC 19798
Self life: 2 years without opening (6 months after opening)
Drum unit
Life expectancy: Approximately 12,000 pages (1 page/job)
The life expectancy varies according to the use condition.
Shelf life: 2 years
The shelf life of toner cartridge and drum unit is guaranteed under the normal condition as below;
(Temperature) Normal condition: 0 to 40°C
(Humidity) Normal condition: 35%RH to 85%RH (without condensation)
* Storage condition at the temperature of 50°C/90%RH: Up to 5 days
* Storage condition at the temperature of -20°C: Up to 5 days
Specifications are subject to change without notice
*1
Toner supplied with the machine.

Brother DCP-L5600DN Specifications

General

Type	all in one
Color	black/gray, multi
Touch Screen	yes
Display Size	3.7 inches
Tray Capacity	50
Output Tray Capacity	150 sheets
Automatic Document Feeder Capacity	70 sheets
Paper Size	ansi a, legal, executive, a4, a5, a6, folio
Paper Handling	letter, legal, executive, a4, a5, a6, envelopes, custom sizes (3.0-8.5" (w), 5.0-14" (l))
Paper Weight	60 grams per square meter
Printing Method	monochromatic
Color Print Speed	0 pages per minute
Mono Print Speed	42 pages per minute
First Page Print Time	7 seconds
Print Resolution Mono	up to 1200 x 1200
Two-Sided Printing	yes
Maximum Number of Pages Per Month	up to 50, 000
Reduction and Enlargement	no
Photo Printing	no
Scanner Type	flatbed
Scan Resolution	up to 1200 x 1200
Duplex Scan	yes
Max Copies	99
Copier Resolution Mono	up to 1200 x 600
Fax Function	no
Cartridges	brother tn820, brother tn850
Number Of Cartridges	1
Internal Memory	yes
Memory Card	no
Network	wired
Connectivity	usb 2.0, ethernet
Mobile Devices Connection	no

Weight and Dimensions

Depth	16.8 inches
Height	16.8 inches
Width	19.5 inches
Net Weight	37.7 pounds
