Brother DCP-L5600DN Service Manual

5-23
Confidential
Paper Size Changes the image development area. Sets the drawing size for PC-Print,
instead of the setting for Paper Size in the menu. When the Paper size is set
on the computer, the setting on the computer supersedes the setting on the
LCD. The default varies depending on the country setting. "Letter" is the
default for U.S.A. / Canada and "A4" is the default for other countries.
Copies Valid for printing from the computer only. When the number of copies is set
on the computer, the setting on the computer supersedes the setting on the
LCD.
Orientation Changes the printing direction. Valid for printing from the computer only.
P-Pos X-Offset Sets the print position offset in the X (landscape) direction. Valid for printing
from the computer only. When the X-Offset is set on the computer, the
setting on the computer supersedes the setting on the LCD.
P-Pos Y-Offset Sets the print position offset in the Y (portrait) direction. Valid for printing
from the computer only. When the Y-Offset is set on the computer, the
setting on the computer supersedes the setting on the LCD.
Auto FF Sets ON or OFF for AutoFF (automatic form feed). Valid for printing from the
computer only.
Auto FF Time Sets the time until timeout after AutoFF is set to ON.
FF Surpress Sets whether to skip blank pages. Valid for printing from the computer only.
On or Off setting of the blank data for copying or faxing cannot be changed
in this setting.
Auto LF Sets the auto linefeed.
Auto CR Sets the auto carriage return. Adds CR to the LF code.
Auto WRAP Sets the auto CRLF by the print width.
Auto Skip Sets whether to skip at the back end / tip of paper. Adds a blank space.
Left Margin Sets the column space at the left side.
Right Margin Set the column space at the right side.
Top Margin Sets the space at the top.
Bottom Margin Sets the space at the bottom.
Lines Sets the number of lines in the PCL.
Error Print Sets the Error Print in the event of a BR-Script 3 error.
LCD Detail description
