Brother DCP-L5600DN Service Manual

6-2
Confidential
 LT
MAIN PCB
NC
1-3
10-12
NC CN6 LT Control PCB CN5 NC
1-3
VDD24
149
7
VDD24
+24V
+24V VDD24 7
4
S0V
258
6 S0V S0V 6
5
MAIN_RXD
367
5 LT_TxD LT_TxD 5
6
RST
476
4 LT_RST LT_RST 4
7
MAIN_TXD
585
3 LT_RxD LT_RxD 3
8
Timing
694
2
LT _T im ing
LT_T iming 2
9
VDD3
7103
1 VDD3
+3.3V
VDD
+3.3V
+3.3V
VDD3 1
10
NC
11 2
NC
TxD1
SELOUT
CN2 NC
11
NC
12 1
NC TXEN SOL1 SOL_OUT 1 NC
12
Reset
+24V
VDD24 2
LT pickup clutch
RxD1
+3.3V
CN1
Timing S0V 1
1
S0V
LED VDD_LTSEN2 2
2
LED_VCC
SEN1 3
3
SEN
TOOL0 CN3
S0V 1
1
S0V
VDD_LTSEN1 2
2
LED_VCC
SEN2 3
3
SEN
CN7
SOL2 SOL_OUT 1
+24V
VDD24 2
LT release clutch
Main body
Main body
LT paper empty sensor
LT Paper feed sensor
To LT2
LT connector
LT
lower
SEN1 SEN2
upper
connector

Brother DCP-L5600DN Specifications

General

Type	all in one
Color	black/gray, multi
Touch Screen	yes
Display Size	3.7 inches
Tray Capacity	50
Output Tray Capacity	150 sheets
Automatic Document Feeder Capacity	70 sheets
Paper Size	ansi a, legal, executive, a4, a5, a6, folio
Paper Handling	letter, legal, executive, a4, a5, a6, envelopes, custom sizes (3.0-8.5" (w), 5.0-14" (l))
Paper Weight	60 grams per square meter
Printing Method	monochromatic
Color Print Speed	0 pages per minute
Mono Print Speed	42 pages per minute
First Page Print Time	7 seconds
Print Resolution Mono	up to 1200 x 1200
Two-Sided Printing	yes
Maximum Number of Pages Per Month	up to 50, 000
Reduction and Enlargement	no
Photo Printing	no
Scanner Type	flatbed
Scan Resolution	up to 1200 x 1200
Duplex Scan	yes
Max Copies	99
Copier Resolution Mono	up to 1200 x 600
Fax Function	no
Cartridges	brother tn820, brother tn850
Number Of Cartridges	1
Internal Memory	yes
Memory Card	no
Network	wired
Connectivity	usb 2.0, ethernet
Mobile Devices Connection	no

Weight and Dimensions

Depth	16.8 inches
Height	16.8 inches
Width	19.5 inches
Net Weight	37.7 pounds
