Brother DCP-L5600DN Service Manual

2-43
Confidential
 Error code 1701
Detected a TT fan failure.
 Error code 1801
A communication error occurred between the ASIC and T2LT control PCB in the engine. (LT
only)
Error code 1802
A communication error occurred between the ASIC and T3LT control PCB ASSY in the
engine. (LT only)
 Error code 1808
A communication error occurred between the ASIC and TT control PCB in the engine.
Step Cause Remedy
1
Malfunction of the TT control
PCB
Install the latest main firmware.
2
Connection failure of the TT fan
harness
Reconnect the TT fan harness.
3
LT/TT connector failure
(machine side or TT side)
Replace the LT/TT connector of the machine
side or TT side.
4 TT fan failure Replace the TT fan.
5 TT control PCB failure Replace the TT control PCB.
6 Main PCB failure Replace the main PCB ASSY.
Step Cause Remedy
1
Malfunction of the LT control
PCB
Install the latest main firmware.
2
An LT/TT connector failure
(machine side or LT side)
Replace the appropriate LT/TT connector of the
machine side or LT side.
3 An LT control PCB failure Replace the appropriate LT control PCB.
4 Main PCB failure Replace the main PCB ASSY.
Step Cause Remedy
1
Malfunction of the TT control
PCB
Install the latest main firmware.
2
LT/TT connector failure
(machine or TT side)
Replace the LT/TT connector on the machine
side or TT side.
3 TT control PCB failure Replace the TT control PCB.
4 Main PCB failure Replace the main PCB ASSY.

Brother DCP-L5600DN Specifications

General

Type	all in one
Color	black/gray, multi
Touch Screen	yes
Display Size	3.7 inches
Tray Capacity	50
Output Tray Capacity	150 sheets
Automatic Document Feeder Capacity	70 sheets
Paper Size	ansi a, legal, executive, a4, a5, a6, folio
Paper Handling	letter, legal, executive, a4, a5, a6, envelopes, custom sizes (3.0-8.5" (w), 5.0-14" (l))
Paper Weight	60 grams per square meter
Printing Method	monochromatic
Color Print Speed	0 pages per minute
Mono Print Speed	42 pages per minute
First Page Print Time	7 seconds
Print Resolution Mono	up to 1200 x 1200
Two-Sided Printing	yes
Maximum Number of Pages Per Month	up to 50, 000
Reduction and Enlargement	no
Photo Printing	no
Scanner Type	flatbed
Scan Resolution	up to 1200 x 1200
Duplex Scan	yes
Max Copies	99
Copier Resolution Mono	up to 1200 x 600
Fax Function	no
Cartridges	brother tn820, brother tn850
Number Of Cartridges	1
Internal Memory	yes
Memory Card	no
Network	wired
Connectivity	usb 2.0, ethernet
Mobile Devices Connection	no

Weight and Dimensions

Depth	16.8 inches
Height	16.8 inches
Width	19.5 inches
Net Weight	37.7 pounds
