Brother DCP-L5600DN Service Manual

2-45
Confidential
 Error code 4500
The number of printable pages of the fuser unit has reached the upper limit.
 Error code 4600
The number of printable pages of the laser unit has reached the upper limit.
 Error code 4B01
Dot counter or develop roller counter of the toner is reaching the upper limit.
Error code 4C01
Dot counter or develop roller counter of the toner has reached the upper limit.
Step Cause Remedy
1
End of life of the fuser unit Replace the fuser unit. Refer to “1.3.31 Reset
counters for consumable parts (function code:
88)” in Chapter 5 to reset the fuser unit counter
after the replacement.
2
Replace the fuser unit with a
new one and reset the fuser unit
counter. If the error display is not
cleared, the main PCB is faulty.
Replace the main PCB ASSY.
Step Cause Remedy
1
End of life of the laser unit Replace the laser unit. Refer to “1.3.31 Reset
counters for consumable parts (function code:
88)” in Chapter 5 to reset the laser unit counter
after the replacement.
2
Replace the laser unit with a
new one and reset the laser unit
counter. If the error display is not
cleared, the main PCB is faulty.
Replace the main PCB ASSY.
Step Cause Remedy
1
Replace the toner cartridge with
a new one. If the error display is
not cleared, the main PCB is
faulty.
Replace the main PCB ASSY.

Brother DCP-L5600DN Specifications

General

Type	all in one
Color	black/gray, multi
Touch Screen	yes
Display Size	3.7 inches
Tray Capacity	50
Output Tray Capacity	150 sheets
Automatic Document Feeder Capacity	70 sheets
Paper Size	ansi a, legal, executive, a4, a5, a6, folio
Paper Handling	letter, legal, executive, a4, a5, a6, envelopes, custom sizes (3.0-8.5" (w), 5.0-14" (l))
Paper Weight	60 grams per square meter
Printing Method	monochromatic
Color Print Speed	0 pages per minute
Mono Print Speed	42 pages per minute
First Page Print Time	7 seconds
Print Resolution Mono	up to 1200 x 1200
Two-Sided Printing	yes
Maximum Number of Pages Per Month	up to 50, 000
Reduction and Enlargement	no
Photo Printing	no
Scanner Type	flatbed
Scan Resolution	up to 1200 x 1200
Duplex Scan	yes
Max Copies	99
Copier Resolution Mono	up to 1200 x 600
Fax Function	no
Cartridges	brother tn820, brother tn850
Number Of Cartridges	1
Internal Memory	yes
Memory Card	no
Network	wired
Connectivity	usb 2.0, ethernet
Mobile Devices Connection	no

Weight and Dimensions

Depth	16.8 inches
Height	16.8 inches
Width	19.5 inches
Net Weight	37.7 pounds
