7-44

Confidential

Fig. 7-81

(6) After replacing the PF kit 1, reset the counter. (Refer to “1.3.37 Reset counters for parts

(Function code 88)” in Chapter 5.)

Assembling Note:

Align the Hole of the Paper feed unit to the Shaft of the Roller holder ASSY and insert it

into the hole.

Paper feed unit

Roller holder ASSY

Hole

Shaft
