Brother HL-5450DN Service Manual

2-14
Confidential
Error
codes
Problem
Refer
to:
Error
codes
Problem
Refer
to:
C300 An unidentified error occurred. 2-50 DD00
Fuser unit error (except error
codes 6A00 to 6F00, 7600,
7800, DE00, and E200)
2-51
C400 An unidentified error occurred. 2-50 DE00
When the center thermistor of
the fuser unit is higher than the
idle temperature, the side
thermistor detected a
temperature lower than the
specified temperature.
2-52
C500 An unidentified error occurred. 2-50 DF00 An unidentified error occurred. 2-52
C600 An unidentified error occurred. 2-50 E000
An error occurred in the ROM
check sum.
2-52
C700
There is insufficient memory to
expand PC-print data.
2-50 E100 Program error 2-52
C800
The memory size allotted for
Secure Print was exceeded
when saving Secure Print data.
2-50 E200
When the center thermistor of
the fuser unit is higher than the
idle temperature, the side
thermistor detected a
temperature higher than the
specified temperature.
2-53
C900
Detected that DIMM was faulty
or was mounted incorrectly.
2-50
E300 An unidentified error occurred. 2-53
CA00 An unidentified error occurred. 2-51 E400 An unidentified error occurred. 2-53
CB00 An unidentified error occurred. 2-51 E600
Write error in the EEPROM of
the main PCB
2-53
CC00 An unidentified error occurred. 2-51 E700 An unidentified error occurred. 2-54
CD00 An unidentified error occurred. 2-51 E800 An unidentified error occurred. 2-54
CE00 An unidentified error occurred. 2-51 E900 An unidentified error occurred. 2-54
CF00 An unidentified error occurred. 2-51 EA00 An unidentified error occurred. 2-54
D000 An unidentified error occurred. 2-51 EB00 An unidentified error occurred. 2-54
D100 An unidentified error occurred. 2-51 EC00 Detected a main fan failure. 2-54
D200 An unidentified error occurred. 2-51 ED00
Communication between the
wireless LAN PCB and the main
PCB cannot be established at
machine startup.
2-54
D300 An unidentified error occurred. 2-51 EE00
Detected communication failure
after communication between
the wireless LAN PCB and the
main PCB was established.
2-54
D400 An unidentified error occurred. 2-51 EF00 The supplied power is unstable. 2-55
D500 An unidentified error occurred. 2-51 F000
Malfunction of the flash memory
on the main PCB
2-55
D600 An unidentified error occurred. 2-51 F100 An unidentified error occurred. 2-55
D700 An unidentified error occurred. 2-51 F200 An unidentified error occurred. 2-55
D800 An unidentified error occurred. 2-51 F300 An unidentified error occurred. 2-55
D900 An unidentified error occurred. 2-51 F400 An unidentified error occurred. 2-55
DA00 An unidentified error occurred. 2-51 F500 An unidentified error occurred. 2-55
DB00 An unidentified error occurred. 2-51 F600 An unidentified error occurred. 2-55
DC00 An unidentified error occurred. 2-51 F800 An unidentified error occurred. 2-55

Brother HL-5450DN Specifications

General

Color	No
N-up printing	2, 4, 9, 16, 25
Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Duplex print speed (black, normal quality, A4/US Letter)	9 ppm
Maximum duty cycle	- pages per month
Recommended duty cycle	1000 - 3500 pages per month
Number of print cartridges	1
Memory type	DDR2
Processor family	Star Sapphire
Maximum internal memory	320 MB
Sound power level (standby)	34 dB
Sound pressure level (printing)	59 dB
Sound pressure level (quiet mode)	54 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	800 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	50 sheets
Custom media width	76.2 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.41 W
Power consumption (standby)	4.7 W
Power consumption (printing)	665 W
Power consumption (PowerSave)	0.6 W
Package weight	11.900 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	371 x 384 x 245 mm
