Brother HL-5450DN Service Manual

2-13
Confidential
Error
codes
Problem
Refer
to:
Error
codes
Problem
Refer
to:
9300
When printing from the MP tray,
the MP paper empty sensor
detected that there was no paper
set in the MP tray.
2-45 AB00 An unidentified error occurred. 2-49
9400
When printing from paper tray 1,
the T1 paper feed sensor
detected that there was no paper
set in paper tray 1.
2-46
AC00 An unidentified error occurred. 2-49
9500
When printing from paper tray 2,
the T2 paper feed sensor
detected that there was no paper
set in paper tray 2.
2-46
AD00 An unidentified error occurred. 2-49
9600
When printing with the tray
designation set to AUTO, the MP
paper empty sensor, T1 paper
feed sensor and T2 paper feed
sensor all detected that there
was no paper set in the MP tray,
paper tray 1 and paper tray 2.
2-47
AE00 An unidentified error occurred. 2-49
9700 An unidentified error occurred. 2-47 AF00 An unidentified error occurred. 2-49
9800 An unidentified error occurred. 2-47 B000 An unidentified error occurred. 2-49
9900
Printing on a paper size not
supported for duplex printing
was attempted from the driver.
2-47
B100 An unidentified error occurred. 2-49
9A00
There is no paper set in the MP
tray when feeding from the MP
tray is designated from the driver.
2-48 B200 An unidentified error occurred. 2-49
9B00 An unidentified error occurred. 2-48 B300 An unidentified error occurred. 2-49
9C00 An unidentified error occurred. 2-48 B400 An unidentified error occurred. 2-49
9D00 An unidentified error occurred. 2-48 B500 An unidentified error occurred. 2-49
9E00 An unidentified error occurred. 2-48 B600 An unidentified error occurred. 2-49
9F00 An unidentified error occurred. 2-48 B700 An unidentified error occurred. 2-49
A000 An unidentified error occurred. 2-48 B800 An unidentified error occurred. 2-49
A100
The front cover sensor detected
that the front cover was open.
2-49
B900 An unidentified error occurred. 2-49
A200 An unidentified error occurred. 2-49 BA00 An unidentified error occurred. 2-49
A300 An unidentified error occurred. 2-49 BB00 An unidentified error occurred. 2-49
A400 An unidentified error occurred. 2-49 BC00 An unidentified error occurred. 2-49
A500 An unidentified error occurred. 2-49 BD00 An unidentified error occurred. 2-49
A600 An unidentified error occurred. 2-49 BE00 An unidentified error occurred. 2-49
A700 An unidentified error occurred. 2-49 BF00 An unidentified error occurred. 2-49
A800 An unidentified error occurred. 2-49 C000
The new toner sensor could not
detect the new toner cartridge
correctly.
2-49
A900 An unidentified error occurred. 2-49 C100 An unidentified error occurred. 2-50
AA00 An unidentified error occurred. 2-49 C200 An unidentified error occurred. 2-50

Brother HL-5450DN Specifications

General

Color	No
N-up printing	2, 4, 9, 16, 25
Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Duplex print speed (black, normal quality, A4/US Letter)	9 ppm
Maximum duty cycle	- pages per month
Recommended duty cycle	1000 - 3500 pages per month
Number of print cartridges	1
Memory type	DDR2
Processor family	Star Sapphire
Maximum internal memory	320 MB
Sound power level (standby)	34 dB
Sound pressure level (printing)	59 dB
Sound pressure level (quiet mode)	54 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	800 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	50 sheets
Custom media width	76.2 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.41 W
Power consumption (standby)	4.7 W
Power consumption (printing)	665 W
Power consumption (PowerSave)	0.6 W
Package weight	11.900 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	371 x 384 x 245 mm
