Configuring your machine for a wireless network (For MFC-9320CW)
34
3
Using the Setup Wizard from the control panel 3
You can configure your Brother machine by using the Setup Wizard function. This is located in the
Network menu on the machine’s control panel. See to the steps below for further information.
a Write down the wireless network settings of your access point or wireless router. If you do not know them,
contact your network administrator or the manufacturer of your access point/router.
Check and record the current wireless network settings.
1
WPA/WPA2-PSK is a Wi-Fi Protected Access Pre-Shared Key, which lets the Brother wireless machine associate with access points using
TKIP or AES encryption (WPA-Personal). WPA2-PSK (AES), WPA-PSK (TKIP/AES) uses a Pre-Shared Key (PSK) that is 8 or more
characters in length, up to a maximum of 63 characters.
2
The WEP key is for 64-bit encrypted networks or 128-bit encrypted networks and can contain both numbers and letters. If you do not know
this information you should see the documentation provided with your access point or wireless router. This key is a 64-bit or 128-bit value
that must be entered in an ASCII or HEXADECIMAL format.
3
This is supported for WPA-PSK only
4
Encryption key, WEP key, Passphrase.
For LEAP and EAP-FAST, record the User Name and Password
Network name:(SSID, ESSID)
Communication Mode Authentication method Encryption mode
Network key
4
Infrastructure Open system
WEP
2
NONE —
Shared key
WEP
2
WPA/WPA2-PSK
1
AES
TKIP
3
LEAP CKIP
EAP-FAST/NONE
EAP-FAST/MS-CHAPv2
EAP-FAST/GTC
AES
TKIP
Ad-hoc Open system
WEP
2
NONE —
For example:
64-bit ASCII: Uses 5 text characters e.g. “Hello” (this is case sensitive)
64-bit Hexadecimal: Uses 10 digits of hexadecimal data e.g. “71f2234aba”
128-bit ASCII: Uses 13 text characters e.g.
“Wirelesscomms” (this is case sensitive)
128-bit Hexadecimal: Uses 26 digits of hexadecimal data
e.g.“71f2234ab56cd709e5412aa3ba”
