Brother MFC-9125CN Service Manual

1-2
Confidential
2. SPECIFICATIONS LIST
2.1 General
*1
The time may change if the machine is performing adjustment of color density or
adjustment of color registration.
Specifications are subject to change without notice.
Model DCP9010CN MFC9010CN MFC9120CN MFC9320CW
Print method Electrophotographic LED printer (Single-pass)
Resolution
600 (main scanning) x 600
(sub scanning) dpi, 2,400 dpi
(600 (main scanning) x 2,400
(sub scanning))
Windows Server
®
2008, Windows Vista
®
, Windows Server
®
2003 x64 Edition, Windows
®
XP Professional x64 Edition,
Windows Server
®
2003, Windows
®
XP Home
Edition/Professional, Windows
®
2000, Mac OS
®
X 10.3.9 or
greater
Print mode Normal printing mode
Economy printing mode (Toner saving mode)
Print speed One side Monochrome/Full Color:
Up to 16/16 ppm (A4 size), Up to 17/17 ppm (Letter size)
* When loading A4 or Letter-size paper from the paper tray.
Duplex
N/A
Warm-up time From Sleep Mode: Less than 27 seconds
From Power OFF → ON: Less than 37 second
* With standard 64 MB RAM, 23 °C (73.4 °F).
First print time
*1
Monochrome: Less than 15 seconds
Full Color: Less than 16 seconds
CPU 300 MHz
Memory Standard 64 MB
Option 1 DIMM slot; expandable up to 576 MB
Interface Hi-Speed USB 2.0,
Ethernet 10/100 BASE-TX
External
TAD,
Hi-Speed
USB 2.0,
Ethernet
10/100
BASE-TX
External
TAD,
Hi-Speed
USB 2.0,
USB Host,
Ethernet
10/100
BASE-TX,
Wireless
Power
consumption
Printing Average 480 W at 25 °C (77 °F)
Ready Average 75 W at 25 °C (77 °F)
Sleep
Average 10 W at 25 °C (77 °F) Average 11
W at 25 °C
(77 °F)
Average 12
W at 25 °C
(77 °F)
Note:
Print speed varies depending on the paper size or media type. For details, refer to
“2.7 Print Speeds with Various Settings” in this chapter.

Brother MFC-9125CN Specifications

General

DVD/CD printing	No
Print technology	LED
Maximum resolution	2400 x 600 DPI
Economical printing	Yes
Print speed (black, normal quality, A4/US Letter)	19 ppm
Fax compatibility	ITU-T G3
Dimensions (WxDxH)	429.3 x 490.2 x 398.8 mm
All-in-one functions	Copy, Fax, Print, Scan
Connectivity technology	Wired
Color all-in-one functions	copy, fax, print, scan
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	25000 pages per month
Number of print cartridges	4
Page description languages	BR-Script 3, PCL 6
Copier resize	25 - 400 %
Maximum copy resolution	- DPI
Maximum number of copies	35 copies
N-in-1 copy function (N=)	2, 4
Copy speed (black, normal quality, A4)	19 cpm
Scan to	CIFS, E-mail, File, FTP, Image, OCR
Scanner type	Flatbed scanner
Input color depth	48 bit
Maximum scan area	A4 / Letter (216 x 297) mm
Image formats supported	BMP, JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	1200 x 2400 DPI
Fax memory	600 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, JPEG, MH, MMR (Fax coding method), MR
Fax transmission speed	2 sec/page
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	100 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	1 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Display	LCD
Market positioning	Business
Direct printing	-
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Client and ServerTELNET Server, HTTP/HTTPS server, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD responder, WebServicesPrint, CIFS Client, SNTP, SSL/TLS
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Client and Server, TELNET Server, HTTP/HTTPS server, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMPv6, LLTD responder, WebServicesPrint, CIFS Client, SNTP, SSL/TLS
Maximum internal memory	576 MB
Sound power level (standby)	30 dB
Sound pressure level (copying)	53 dB
AC input voltage	120 V
AC input frequency	50 - 60 Hz
Power consumption (off)	11 W
Power consumption (PowerSave)	75 W
Power consumption (average operating)	480 W
Package weight	28490 g
Operating relative humidity (H-H)	20 - 80 %
