Brother MFC-9125CN Service Manual

1-13
Confidential
<Wireless network>
(MFC9320CW)
*5
If you want to use the IPv6 protocol, visit http://solutions.brother.com/ for more information.
Specifications are subject to change without notice.
Network node type NC-7500w
Operating system
support
Windows Server
®
2008, Windows Vista
®
, Windows Server
®
2003
x64 Edition, Windows
®
XP Professional x64 Edition, Windows
Server
®
2003, Windows
®
XP Home Edition/Professional, Windows
®
2000 Professional, Mac OS
®
X 10.3.9 or greater
Protocol support TCP/IP: IPv4
ARP, RARP, BOOTP, DHCP, APIPA (Auto IP),
WINS/NetBIOS name resolution, DNS Resolver,
mDNS, LLMNR responder, LPR/LPD, Custom
Raw Port/Port9100, IPP/IPPS, FTP Server,
TELNET Server, HTTP/HTTPS server, TFTP
client and server, SMTP Client, APOP, POP before
SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP,
LLTD responder, Web Services Print, SSL/TLS,
CIFS client
TCP/IP: IPv6
*5
NDP, RA, DNS resolver, mDNS, LLMNR
responder, LPR/LPD, Custom Raw Port/
Port9100, IPP/IPPS, FTP Server, TELNET
Server, HTTP/HTTPS server, TFTP client and
server, SMTP Client, APOP, POP before SMTP,
SMTP-AUTH, SNMPv1/v2c/v3, ICMPv6, LLTD
responder, Web Services Print, SSL/TLS,
CIFS client
Network type IEEE 802.11 b/g wireless
Frequency 2412 - 2472 MHz
RF channels US/Canada 1 - 11
Japan 802.11 b: 1 - 14, 802.11 g: 1 - 13
Others 1 - 13
Communication mode Infrastructure, Ad-hoc (802.11 b only)
Data rate 802.11 b 11/5.5/2/1 Mbps
802.11 g 54/48/36/24/18/12/11/9/6/5.5/2/1 Mbps
Link distance 70 m (233 ft.) at lowest data rate (The distance rate will vary upon
environment and other equipment location.)
Network security SSID/ESSID, WEP 64/128 bit, WPA-PSK (TKIP/AES),
WPA2-PSK (AES), LEAP (CKIP), EAP-FAST (TKIP/AES)
Network printing Windows Vista
®
, Windows Server
®
2003, Windows
®
XP and
Windows
®
2000 TCP/IP printing
Mac OS
®
X 10.3.9 or greater printing

Brother MFC-9125CN Specifications

General

DVD/CD printing	No
Print technology	LED
Maximum resolution	2400 x 600 DPI
Economical printing	Yes
Print speed (black, normal quality, A4/US Letter)	19 ppm
Fax compatibility	ITU-T G3
Dimensions (WxDxH)	429.3 x 490.2 x 398.8 mm
All-in-one functions	Copy, Fax, Print, Scan
Connectivity technology	Wired
Color all-in-one functions	copy, fax, print, scan
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	25000 pages per month
Number of print cartridges	4
Page description languages	BR-Script 3, PCL 6
Copier resize	25 - 400 %
Maximum copy resolution	- DPI
Maximum number of copies	35 copies
N-in-1 copy function (N=)	2, 4
Copy speed (black, normal quality, A4)	19 cpm
Scan to	CIFS, E-mail, File, FTP, Image, OCR
Scanner type	Flatbed scanner
Input color depth	48 bit
Maximum scan area	A4 / Letter (216 x 297) mm
Image formats supported	BMP, JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	1200 x 2400 DPI
Fax memory	600 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, JPEG, MH, MMR (Fax coding method), MR
Fax transmission speed	2 sec/page
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	100 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	1 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Display	LCD
Market positioning	Business
Direct printing	-
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Client and ServerTELNET Server, HTTP/HTTPS server, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD responder, WebServicesPrint, CIFS Client, SNTP, SSL/TLS
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Client and Server, TELNET Server, HTTP/HTTPS server, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMPv6, LLTD responder, WebServicesPrint, CIFS Client, SNTP, SSL/TLS
Maximum internal memory	576 MB
Sound power level (standby)	30 dB
Sound pressure level (copying)	53 dB
AC input voltage	120 V
AC input frequency	50 - 60 Hz
Power consumption (off)	11 W
Power consumption (PowerSave)	75 W
Power consumption (average operating)	480 W
Package weight	28490 g
Operating relative humidity (H-H)	20 - 80 %
