5-20
Confidential
14 Main Fan ASSY, LV Fan ASSY
15 Develop Release Sensor PCB ASSY, Top Cover Open Switch,
Toner LED PCB ASSY
Side frame R
Hook
Hook
Hook
Main fan ASSY
LV fan ASSY
High-voltage power supply
PCB ASSY
Front
Hook
Hook
Hook
Side frame R
Top cover open switch
Toner LED PCB ASSY
HVPS control PCB ASSY
Develop release sensor
PCB ASSY
Front
