8.66 Pick-up Sector Gear Spring/Friction Spring
(1) Remove the Gear 27/72 from the Side frame L.
Fig. 5-191
(2) Remove the Pick-up sector gear spring from the Hook of the Cleaner PF gear cover.
Fig. 5-192
Side frame L
Gear 27/72
Cleaner PF gear cover
Hook
Pick-up sector gear spring
