Brother MFC-9125CN Service Manual

7-2
Confidential
1.3 List of Maintenance-mode Functions
* The functions shaded in the table above are user-accessible.
Function
code
Function Refer to:
01 EEPROM parameter initialization 1.4.1 (7-3)
05 Printout of scanning compensation data 1.4.2 (7-4)
06 Placement of scanner module position for transportation 1.4.3 (7-7)
08 ADF performance test 1.4.4 (7-7)
09 Monochrome image quality test pattern 1.4.5 (7-8)
10 Worker switch (WSW) setting 1.4.6 [1] (7-9)
11 Printout of worker switch (WSW) data 1.4.6 [2] (7-12)
12 Operational check of LCD 1.4.7 (7-13)
13 Operational check of control panel button 1.4.8 (7-14)
25 Software version check 1.4.9 (7-15)
32 Operational check of sensors 1.4.10 (7-16)
43 PC print function 1.4.11 (7-20)
45 Not-disclosed-to-users functions 1.4.12 (7-23)
52 EEPROM customizing (User-accessible) 1.4.13 (7-27)
53 Received data transfer function 1.4.14 (7-28)
54 Fine adjustment of scan start/end positions 1.4.15 (7-30)
55 Acquisition of white level data 1.4.16 (7-31)
66 Adjustment of color registration 1.4.17 (7-32)
67 Continuous print test 1.4.18 (7-35)
68 LED test pattern print 1.4.19 (7-37)
69 Frame pattern print 1.4.20 (7-39)
71 Color test pattern 1.4.21 (7-41)
72 Sensitivity adjustment of density sensor 1.4.22 (7-43)
74 Setting by country 1.4.23 (7-44)
75 Sensitivity adjustment of registration mark sensor and
check of belt surface
1.4.24 (7-46)
77 Printout of maintenance information 1.4.25 (7-48)
78 Operational check of fans 1.4.26 (7-49)
80 Display of the machine’s log 1.4.27 (7-50)
82 Error code indication 1.4.28 (7-53)
83 Developing bias voltage correction 1.4.29 (7-54)
87 Output of transmission log to the telephone line 1.4.30 (7-55)
88 Counter reset after replacing the fuser unit and paper
feeding kit
1.4.31 (7-55)
91 EEPROM parameter Initialization 1.4.1 (7-3)
99 Exit from the maintenance mode 1.4.32 (7-55)

Brother MFC-9125CN Specifications

General

DVD/CD printing	No
Print technology	LED
Maximum resolution	2400 x 600 DPI
Economical printing	Yes
Print speed (black, normal quality, A4/US Letter)	19 ppm
Fax compatibility	ITU-T G3
Dimensions (WxDxH)	429.3 x 490.2 x 398.8 mm
All-in-one functions	Copy, Fax, Print, Scan
Connectivity technology	Wired
Color all-in-one functions	copy, fax, print, scan
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	25000 pages per month
Number of print cartridges	4
Page description languages	BR-Script 3, PCL 6
Copier resize	25 - 400 %
Maximum copy resolution	- DPI
Maximum number of copies	35 copies
N-in-1 copy function (N=)	2, 4
Copy speed (black, normal quality, A4)	19 cpm
Scan to	CIFS, E-mail, File, FTP, Image, OCR
Scanner type	Flatbed scanner
Input color depth	48 bit
Maximum scan area	A4 / Letter (216 x 297) mm
Image formats supported	BMP, JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	1200 x 2400 DPI
Fax memory	600 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, JPEG, MH, MMR (Fax coding method), MR
Fax transmission speed	2 sec/page
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	100 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	1 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Display	LCD
Market positioning	Business
Direct printing	-
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Client and ServerTELNET Server, HTTP/HTTPS server, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD responder, WebServicesPrint, CIFS Client, SNTP, SSL/TLS
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Client and Server, TELNET Server, HTTP/HTTPS server, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMPv6, LLTD responder, WebServicesPrint, CIFS Client, SNTP, SSL/TLS
Maximum internal memory	576 MB
Sound power level (standby)	30 dB
Sound pressure level (copying)	53 dB
AC input voltage	120 V
AC input frequency	50 - 60 Hz
Power consumption (off)	11 W
Power consumption (PowerSave)	75 W
Power consumption (average operating)	480 W
Package weight	28490 g
Operating relative humidity (H-H)	20 - 80 %
