8.24 Document Hold ASSY
(1) Turn the Lower document chute ASSY upside down.
(2) Release the two Pins to remove the Document hold ASSY and Document hold spring
from the Lower document chute ASSY.
Fig. 5-66
Lower document chute ASSY
Pin
Document hold ASSY
Document hold spring
Hook
Hook
Pin
2a
2a
2c
2d
2b
