■ WSW14 (AUTO ANS facility setting)
- Selectors 1 through 4: Frequency band selection for incoming calling signal (CI)
These selectors are used to select the frequency band of CI for activating the AUTO ANS facility.
In the French models, if the user sets the PBX to OFF from the control panel, the setting made by
selectors 1 and 2 will take no effect and the frequency's lower limit will be fixed to 32 Hz. (Even if the
setting made by these selectors does not apply, it will be printed on the configuration list.)
- Selectors 5 through 8: No. of rings in AUTO ANS mode
These selectors set the number of rings to initiate the AUTO ANS facility.
Selector No. Function Setting and Specifications
1
2
Frequency band selection (lower
limit) for incoming calling signal (CI)
No. 1 2
0 0: 13 Hz
0 1: 15 Hz
1 0: 23 Hz
1 1: 20 Hz
3
4
Frequency band selection (upper
limit) for incoming calling signal (CI)
No. 3 4
0 0: 30 Hz
0 1: 55 Hz
1 0: 70 Hz
1 1: 200 Hz (China: 80 Hz)
5
l
8
No. of rings in AUTO ANS mode
No. 5 6 7 8
0 0 0 0: Fixed to once
0 0 0 1: 1 to 6 times
0 0 1 0: 1 to 8 times
0 0 1 1: 2 to 8 times
0 1 0 0: 1 to 2 times
0 1 0 1: 1 to 3 times
0 1 1 0: 1 to 4 times
0 1 1 1: 1 to 5 times
1 0 0 0: 2 to 3 times
1 0 0 1: 2 to 4 times
1 0 1 0: 2 to 5 times
1 0 1 1: 2 to 6 times
1 1 0 0: 1 to 10 times
1 1 0 1: 2 to 10 times
1 1 1 0: 3 to 5 times
1 1 1 1: 4 to 10 times

Brother MFC-9125CN Specifications

General

DVD/CD printing	No
Print technology	LED
Maximum resolution	2400 x 600 DPI
Economical printing	Yes
Print speed (black, normal quality, A4/US Letter)	19 ppm
Fax compatibility	ITU-T G3
Dimensions (WxDxH)	429.3 x 490.2 x 398.8 mm
All-in-one functions	Copy, Fax, Print, Scan
Connectivity technology	Wired
Color all-in-one functions	copy, fax, print, scan
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	25000 pages per month
Number of print cartridges	4
Page description languages	BR-Script 3, PCL 6
Copier resize	25 - 400 %
Maximum copy resolution	- DPI
Maximum number of copies	35 copies
N-in-1 copy function (N=)	2, 4
Copy speed (black, normal quality, A4)	19 cpm
Scan to	CIFS, E-mail, File, FTP, Image, OCR
Scanner type	Flatbed scanner
Input color depth	48 bit
Maximum scan area	A4 / Letter (216 x 297) mm
Image formats supported	BMP, JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	1200 x 2400 DPI
Fax memory	600 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, JPEG, MH, MMR (Fax coding method), MR
Fax transmission speed	2 sec/page
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	100 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	1 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Display	LCD
Market positioning	Business
Direct printing	-
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Client and ServerTELNET Server, HTTP/HTTPS server, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD responder, WebServicesPrint, CIFS Client, SNTP, SSL/TLS
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Client and Server, TELNET Server, HTTP/HTTPS server, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMPv6, LLTD responder, WebServicesPrint, CIFS Client, SNTP, SSL/TLS
Maximum internal memory	576 MB
Sound power level (standby)	30 dB
Sound pressure level (copying)	53 dB
AC input voltage	120 V
AC input frequency	50 - 60 Hz
Power consumption (off)	11 W
Power consumption (PowerSave)	75 W
Power consumption (average operating)	480 W
Package weight	28490 g
Operating relative humidity (H-H)	20 - 80 %
