■ WSW26 (Function setting 4)
- Selector 3: Dialing during document reading into the temporary memory in
inmemory message transmission
If this selector is set to “0,” the machine waits for document reading into the memory to complete
and then starts dialing. This enables the machine to list the total number of pages in the header of
the facsimile message.
- Selectors 4 and 5: No. of CNG cycles to be detected (when the line is connected via
the external telephone except in the external TAD mode or via the
built-in telephone)
The machine interprets a CNG as an effective signal if it detects the CNG by the number of cycles
specified by these selectors when the line is connected via the external telephone except in the
external TAD mode or via the built-in telephone.
- Selectors 6 and 7: No. of CNG cycles to be detected (when the line is connected via
the external telephone in the external TAD mode, via the built-in
telephone in the TAD mode, or via the machine in the automatic
reception of the F/T mode)
The machine interprets a CNG as an effective signal if it detects the CNG by the number of cycles
specified by these selectors when the line is connected via the external telephone in the external
TAD mode, via the built-in telephone in the TAD mode, or via the machine in the automatic reception
of the F/T mode.
Selector No. Function Setting and Specifications
1
2
Not used.
3
Dialing during document reading into
the temporary memory in inmemory
message transmission
0: Disable
1: Enable
4
5
No. of CNG cycles to be detected
(when the line is connected via the
external telephone except in the
external TAD mode or via the built-in
telephone)
In the case of Selector 3=0 in WSW54.
No. 4 5
0 0: 0.5
0 1: 1
1 0: 1.5
1 1: 2
(A)
(B)
(C)
(D)
In the case of Selector 3=1 in WSW54.
No. 4 5
0 0: 2.5
0 1: 3
1 0: 3.5
1 1: 4
(A)
(B)
(C)
(D)
6
7
No. of CNG cycles to be detected
(when the line is connected via the
external telephone in the external
TAD mode, via the built-in telephone
in the TAD mode, or via the machine
in the automatic reception of the F/T
mode)
In the case of Selector 6=0 in WSW58.
No. 6 7
0 0: 0.5
0 1: 1
1 0: 1.5
1 1: 2
(A)
(B)
(C)
(D)
In the case of Selector 6=1 in WSW58.
No. 6 7
0 0: 2.5
0 1: 3
1 0: 3.5
1 1: 4
(A)
(B)
(C)
(D)
8 Not used.
