Brother MFC-9125CN Service Manual

App.1-47
Confidential
■ WSW59 (Function setting 24)
- Selector 1: USB serial number (SN) transmission enabled/disabled
This is intended to prevent the problem of a continued increase in USB ports when serial numbers are
transmitted from the MFC to a Windows Vista-based PC.
It is intended only to prevent a problem specific to Windows Vista; its default setting is “0: USB SN enabled.”
- Selector 2: Extension of the waiting time between ANSam and DIS
Setting this selector to “0” extends the waiting time between the ANSam and DIS in order to secure
the time required for switching the calling machine's echo suppressor in transmission from a G3 to
G4 FAX machine.
- Selectors 3 through 7: Checking of the specified character code set when displaying
or printing the folder/file names stored in memory cards or
USB flash memory drives
The language is switched to a relevant one when a file name cannot be identified.
- Selector 8: Improvement of DTMF detection function (to minimize the effects of
momentary power failure or noise)
Be effective only MFC-9120CN/9125CN/9320CW/9325CW.
Selector No. Function Setting and Specifications
1
USB serial number (SN)
transmission enabled/disabled
0: USB serial number transmitted/USB
serial number not transmitted
1: Frame length selection
2
Extension of the waiting time
between ANSam and DIS
0: Enable (default)
1: Disable
3
l
7
Checking of the specified character
code set when displaying or printing
the folder/file names stored in
memory cards or USB flash memory
drives
No. 34567
00000: ASC11 (default for USA/
European models)
00001: Latin1 (CP1252)
00010: Latin2 (CP1250)
00011: Cyrillic (CP1251)
00100: SJIS (CP932) (default for
Japanese models)
00101: Thai (CP874)
00110: Korean (CP949)
00111: Traditional Chinese (CP950)
01000: Simplified Chinese (CP936)
(default for Chinese and
Asia & Pacific models)
01001: Arabic (CP1256)
01010:
| Reserved.
11111:
8
Improvement of DTMF detection
function (to minimize the effects of
momentary power failure or noise)
0: Disable (default)
1: Enable

Brother MFC-9125CN Specifications

General

DVD/CD printing	No
Print technology	LED
Maximum resolution	2400 x 600 DPI
Economical printing	Yes
Print speed (black, normal quality, A4/US Letter)	19 ppm
Fax compatibility	ITU-T G3
Dimensions (WxDxH)	429.3 x 490.2 x 398.8 mm
All-in-one functions	Copy, Fax, Print, Scan
Connectivity technology	Wired
Color all-in-one functions	copy, fax, print, scan
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	25000 pages per month
Number of print cartridges	4
Page description languages	BR-Script 3, PCL 6
Copier resize	25 - 400 %
Maximum copy resolution	- DPI
Maximum number of copies	35 copies
N-in-1 copy function (N=)	2, 4
Copy speed (black, normal quality, A4)	19 cpm
Scan to	CIFS, E-mail, File, FTP, Image, OCR
Scanner type	Flatbed scanner
Input color depth	48 bit
Maximum scan area	A4 / Letter (216 x 297) mm
Image formats supported	BMP, JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	1200 x 2400 DPI
Fax memory	600 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, JPEG, MH, MMR (Fax coding method), MR
Fax transmission speed	2 sec/page
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	100 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	1 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Display	LCD
Market positioning	Business
Direct printing	-
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Client and ServerTELNET Server, HTTP/HTTPS server, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD responder, WebServicesPrint, CIFS Client, SNTP, SSL/TLS
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Client and Server, TELNET Server, HTTP/HTTPS server, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMPv6, LLTD responder, WebServicesPrint, CIFS Client, SNTP, SSL/TLS
Maximum internal memory	576 MB
Sound power level (standby)	30 dB
Sound pressure level (copying)	53 dB
AC input voltage	120 V
AC input frequency	50 - 60 Hz
Power consumption (off)	11 W
Power consumption (PowerSave)	75 W
Power consumption (average operating)	480 W
Package weight	28490 g
Operating relative humidity (H-H)	20 - 80 %
