Brother MFC-9140CDN Service Manual

5-61
Confidential
TTLCOPY:00000000 Number of copy pages
CL_COPY:00000000 Number of color copy pages
MN_COPY:00000000 Number of monochrome copy pages
TTLPCPT:00000000 Number of PC prints made
CL_PCPT:00000000 Total number of PC color printed pages
MN_PCPT:00000000 Total number of PC monochrome printed pages
TTLFAX:00000000 Number of List/FAX outputs made
CL_FAX:00000000 Total number of color List/FAX printed pages
MN_FAX:00000000 Total number of monochrome List/FAX printed pages
CCVRGUSI:4.32% Average coverage of cyan toner cartridge in use
CCVRGACC:3.47% Accumulated average coverage of cyan toner cartridge
MCVRGUSI:4.32% Average coverage of magenta toner cartridge in use
MCVRGACC:3.47% Accumulated average coverage of magenta toner cartridge
YCVRGUSI:4.32% Average coverage of yellow toner cartridge in use
YCVRGACC:3.47% Accumulated average coverage of yellow toner cartridge
KCVRGUSI:4.32% Average coverage of black toner cartridge in use
KCVRGACC:3.47% Accumulated average coverage of black toner cartridge
CDRUM:00000000 Number of cyan drum rotations
MDRUM:00000000 Number of magenta drum rotations
YDRUM:00000000 Number of yellow drum rotations
KDRUM:00000000 Number of black drum rotations
CTN_RND: 00000000 Number of cyan developer roller rotations
MTN_RND: 00000000 Number of magenta developer roller rotations
YTN_RND: 00000000 Number of yellow developer roller rotations
KTN_RND: 00000000 Number of black developer roller rotations
MN_PG:00000000 Number of pages printed on paper fed from manual feed slot
TR1_PG:00000000 Number of pages printed on paper fed from paper tray
DX_PG:00000000 Number of sheets where two-sided are printed
A4+LTR:00000000 Total of pages printed on A4 and letter size paper
LG+FOL:00000000 Total of pages printed on legal and folio size paper
B5+EXE:00000000 Total of pages printed on B5 and EXE size paper
ENVLOP:00000000 Number of pages printed on envelopes
A5 :00000000 Number of pages printed on A5 size paper
OTHER :00000000 Total of pages printed on paper other than the above
PLTNRE:00000000 Total of pages printed on plain, thin, and recycled paper
TKTRBD:00000000 Total of pages printed on thick, thicker paper and bond paper
ENVTYP:00000000 Total of pages printed on envelopes, envelopes (thick), and
envelopes (thin)
LABEL:00000000 Number of pages printed on label
LCD Description

Brother MFC-9140CDN Specifications

General

Print technology	LED
Maximum resolution	600 x 2400 DPI
Economical printing	Yes
Duplex printing mode	Auto
Warm-up time (from sleep mode)	24 s
Time to first page (black, normal)	16 s
Print speed (black, normal quality, A4/US Letter)	22 ppm
Duplex print speed (black, normal quality, A4/US Letter)	3.5 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4, 9, 16, 25
Time to first copy (black, normal)	19 s
Time to first copy (color, normal)	22 s
Copy speed (black, normal quality, A4)	22 cpm
Scan to	E-mail, E-mail Server, File, FTP, Image, OCR
Scan drivers	ICA, ISIS, TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Film scanning	No
Grayscale levels	256
Input color depth	48 bit
Maximum scan area	216 x 356 mm
Output color depth	24 bit
Image formats supported	JPG, PNG, TIF
Maximum scan resolution	19200 x 19200 DPI
Document formats supported	PDF
Optical scanning resolution	1200 x 2400 DPI
Faxing	Color faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax transmission speed	2 sec/page
Fax speed dialing (max numbers)	200
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Recommended duty cycle	300 - 1500 pages per month
Number of print cartridges	4
Page description languages	BR-Script 3, PCL 6
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	100 sheets
Auto document feeder (ADF) input capacity	35 sheets
Custom media width	76.2 - 215.9 mm
Custom media length	116 - 355.6 mm
Paper tray media types	Glossy paper, Heavy paper, Labels, Plain paper, Pre-Printed, Recycled paper, Thin paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	64 - 90 g/m²
Display	TFT
Control type	Touch
Product color	Black, White
Display diagonal	3.7 \
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Wi-Fi	-
Cabling technology	10/100Base-T(X)
Security algorithms	HTTPS, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print
Sound power level (standby)	33 dB
Sound pressure level (printing)	53 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.05 W
Power consumption (standby)	70 W
Power consumption (PowerSave)	7.5 W
Power consumption (average operating)	380 W
Package depth	534 mm
Package width	602 mm
Package height	565 mm
Package weight	27900 g
Mac operating systems supported	Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012
Sustainability certificates	Nordic Swan Ecolabel, Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	483 mm
Width	410 mm
