Brother MFC-9140CDN Service Manual

5-62
Confidential
HAGAKI:00000000 Number of pages printed on post card
GLOSSY:00000000 Number of pages printed on glossy paper
TTL_JAM:00000000 Total of jammed sheets
MN_JAM:00000000 Number of sheets jammed in the manual feed slot
TR1_JAM:00000000 Number of sheets jammed in the paper tray
IN_JAM:00000000 Number of sheets jammed inside the machine
RE_JAM:00000000 Number of sheets jammed in paper eject section and back cover
DX_JAM:00000000 Number of sheets jammed during two-sided printing
POWER:00000375 Total hours of current conduction
PWRCNT:00000000 Number of times that the power is turned ON
MACERR_01:0000
*3
Machine error history (Past 10 error history)
CTN_CH:0000
*4
Number of times that the cyan toner cartridge has been replaced
MTN_CH:0000
*4
Number of times that the magenta toner cartridge has been
replaced
YTN_CH:0000
*4
Number of times that the yellow toner cartridge has been replaced
KTN_CH:0000
*4
Number of times that the black toner cartridge has been replaced
CDRM_CH:0000
*4
Number of times that the cyan drum unit has been replaced
MDRM_CH:0000
*4
Number of times that the magenta drum unit has been replaced
YDRM_CH:0000
*4
Number of times that the yellow drum unit has been replaced
KDRM_CH:0000
*4
Number of times that the black drum unit has been replaced
WTNR_CH:0000
*4
Number of times that the waste toner box has been replaced
BELT_CH:0000 Number of times that the belt unit has been replaced
FUSR_CH:0000
*4
Number of times that the fuser unit has been replaced
PFK1_CH:0000
*4
Number of times that the PF kit 1 has been replaced
CTN_PG1:00000000 Number of pages printed from the currently installed cyan toner
cartridge
CTN_PG2:00000000 Number of pages printed from the previous installed cyan toner
cartridge
MTN_PG1:00000000 Number of pages printed from the currently installed magenta
toner cartridge
MTN_PG2:00000000 Number of pages printed from the previous installed magenta
toner cartridge
YTN_PG1:00000000 Number of pages printed from the currently installed yellow toner
cartridge
YTN_PG2:00000000 Number of pages printed from the previous installed yellow toner
cartridge
KTN_PG1:00000000 Number of pages printed from the currently installed black toner
cartridge
KTN_PG2:00000000 Number of pages printed from the previous installed black toner
cartridge
WTNR_PG:00000000 Number of pages printed from the waste toner box
LCD Description

Brother MFC-9140CDN Specifications

General

Print technology	LED
Maximum resolution	600 x 2400 DPI
Economical printing	Yes
Duplex printing mode	Auto
Warm-up time (from sleep mode)	24 s
Time to first page (black, normal)	16 s
Print speed (black, normal quality, A4/US Letter)	22 ppm
Duplex print speed (black, normal quality, A4/US Letter)	3.5 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4, 9, 16, 25
Time to first copy (black, normal)	19 s
Time to first copy (color, normal)	22 s
Copy speed (black, normal quality, A4)	22 cpm
Scan to	E-mail, E-mail Server, File, FTP, Image, OCR
Scan drivers	ICA, ISIS, TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Film scanning	No
Grayscale levels	256
Input color depth	48 bit
Maximum scan area	216 x 356 mm
Output color depth	24 bit
Image formats supported	JPG, PNG, TIF
Maximum scan resolution	19200 x 19200 DPI
Document formats supported	PDF
Optical scanning resolution	1200 x 2400 DPI
Faxing	Color faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax transmission speed	2 sec/page
Fax speed dialing (max numbers)	200
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Recommended duty cycle	300 - 1500 pages per month
Number of print cartridges	4
Page description languages	BR-Script 3, PCL 6
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	100 sheets
Auto document feeder (ADF) input capacity	35 sheets
Custom media width	76.2 - 215.9 mm
Custom media length	116 - 355.6 mm
Paper tray media types	Glossy paper, Heavy paper, Labels, Plain paper, Pre-Printed, Recycled paper, Thin paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	64 - 90 g/m²
Display	TFT
Control type	Touch
Product color	Black, White
Display diagonal	3.7 \
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Wi-Fi	-
Cabling technology	10/100Base-T(X)
Security algorithms	HTTPS, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print
Sound power level (standby)	33 dB
Sound pressure level (printing)	53 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.05 W
Power consumption (standby)	70 W
Power consumption (PowerSave)	7.5 W
Power consumption (average operating)	380 W
Package depth	534 mm
Package width	602 mm
Package height	565 mm
Package weight	27900 g
Mac operating systems supported	Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012
Sustainability certificates	Nordic Swan Ecolabel, Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	483 mm
Width	410 mm
