9.49 Encoder Strip Guard Film

(1) Release the Encoder strip guard film from the Encoder strip spring.

(2) Remove the Encoder strip guard film from the CR frame ASSY.

Fig. 3-120

Encoder strip spring

Encoder strip guard film

Encoder strip spring

Encoder strip guard film

1a

1b

2

CR frame ASSY

<Front>

<Rear>
