Brother MFC-J3520 Service Manual

Confidential
2-44

Error Code 8A
PF encoder sensor cannot detect rotation of the paper feed motor.
User Check
- Remove the jammed paper in jam clear cover part, platen part and front part.
 Error Code 8C
Excessive current protection activated for the driver IC during paper feed motor
operation.
User Check
- Remove the jammed paper in jam clear cover part, platen part and front part.
PAPER JAM LCD
Step Cause Solution
1 Foreign materials in the
feeding path
Remove foreign materials.
2 Paper feed motor harness
connection failure
Reconnect the paper feed motor harness.
3 PF encoder sensor harness
connection defective
Reconnect the PF encoder sensor harness.
4 PF roller belt out of place Set the PF roller belt into place.
5 PF encoder sensor defective Replace the PF encoder sensor PCB ASSY.
6 PF encoder disk defective Replace the PF encoder disk.
7 Paper feed motor defective Replace the paper feed motor.
8 Main PCB defective Replace the main PCB ASSY.
PAPER JAM LCD
Step Cause Solution
1 Foreign materials in the
feeding path
Remove foreign materials.
2 PF encoder sensor defective Replace the PF encoder sensor PCB ASSY.
3 Paper feed motor defective Replace the paper feed motor.
4 Main PCB defective Replace the main PCB ASSY.
