Page #55 background image
Confidential
2-21
4 TROUBLESHOOTING
4.1 Error Cause and Solutions
Error Code 13
Defective during duplex-printing
Registration sensor detects paper feed condition at out of specified timing during
switchback.
User Check
- Check whether the recording paper being used is within the specification.
Error Code 15
Paper jam during duplex ejecting
Recording paper is not able to be ejected since it is longer than 840 mm when ejecting
the paper.
User Check
- Remove the jammed paper.
- Check whether the recording paper being used is within the specification.
- Firmly set the paper tray to the rear end.
Paper Jam LCD
Step Cause Solution
1 Switchback actuator caught on
the surrounding parts
Set the switchback frame ASSY into place.
2 Registration actuator caught
on the surrounding parts
Set the registration actuator into place.
3 Registration sensor defective Replace the registration sensor PCB ASSY.
4 Main PCB defective Replace the main PCB ASSY.
Paper Jam LCD
Step Cause Solution
1 Foreign materials in the
recording paper path
Remove foreign materials.
2 Main PCB defective Replace the main PCB ASSY.
