Brother MFC-J3520 Service Manual

Confidential
2-20
Code 1 Code 2 Cause
Refer to
page:
A8 01 Receive RTN or PIN or ERR (sending side.)
Section 4.9.3
"A communications
error occurs"
A9 01 Send RTN or PIN or ERR (receiving side.)
AA 18 Receive buffer full during receiving into memory.
B0 02 Unable to receive the next-page data.
B0 03
Unable to receive polling even during turn-around
transmission due to call reservation.
B0 04
PC interface error
BF 01
Communication canceled by depressing X key
before confirming FAX communication.
BF 02
Communication canceled by depressing X key after
confirming FAX communication.
C0 01
No common modulation mode or polling failed.
C0 02
Unable to detect JM.
C0 03
Unable to detect CM.
C0 04
Unable to detect CJ.
C0 10
V. 34 negotiation or training not finished.
C0 11
Modem error detected during V. 34 negotiation or
training.
C0 20
Modem error detected during sending of
commands.
C0 21
Modem error detected during receiving of
commands.
C0 22
Control channel connection time-out.
C0 30
Modem error detected during sending of image
signals.
C0 31
Modem error detected during receiving of image
signals.
E0 01
Failed to detect 1,300 Hz signal in burn-in
operation.
E0 02
Failed to detect PB signals in burn-in operation.
E0 03
Command not detected from RS232C in burn-in.

Brother MFC-J3520 Specifications

General

Print Technology	Inkjet
Duplex Printing	Yes
Fax Modem Speed	33.6 kbps
Functions	Print, Copy, Scan, Fax
Standard Paper Capacity	250 sheets
Mobile Printing	Yes
Max Print Resolution	6000 x 1200 dpi
Scanner Type	Flatbed + ADF
Max Scan Resolution	1200 x 2400 dpi
Connectivity	USB, Ethernet, Wi-Fi
Automatic Document Feeder (ADF)	Yes
Ink Cartridges	Black, Cyan, Magenta, Yellow
Print Speed (Black)	Up to 35 ppm (draft), 12 ppm (ISO)
Print Speed (Color)	27 ppm
Display	2.7" Touchscreen Color LCD
