Brother MFC-J3520 Service Manual

5-35
Confidential
For the paper feed roller alone adjustment
(1) Press the 5 and 8 keys in this order in the initial stage of the maintenance mode.
The "Select 58?" appears on the LCD.
(2) Press the Mono Start key.
The "1. ALL" appears on the LCD.
(3) Press the key three times.
The "1. PF_ONLY" appears on the LCD.
(4) Press the 1 key.
The "PF_ONLY NO. +0" appears on the LCD.
(5) On the pfadj1 pattern (see page 5-36), check the PF0 row of blocks. In the same
way as in step (4) of the adjustment of all paper feeding correction values, enter
the number of the block that is the least uneven print and then press the SET key.
Press the X key to return the machine to the initial stage of the maintenance mode.
For corrugation feed adjustment
(1) Press the 5 and 8 keys in this order in the initial stage of the maintenance mode.
The "Select 58?" appears on the LCD.
(2) Press the Mono Start key.
The "1. ALL" appears on the LCD.
(3) Press the key four times.
The "1.COR_FEED(T2)" appears on the LCD.
(4) Press the 1 key.
The "COR_FEED NO. +0" appears on the LCD.
(5) On the pfadj2 pattern (see page 5-37), check the CORF row of blocks. In the same
way as in step (4) of the adjustment of all paper feeding correction values, enter
the number of the block that is the least uneven print and then press the SET key.
Press the X key to return the machine to the initial stage of the maintenance mode.

Brother MFC-J3520 Specifications

General

Print Technology	Inkjet
Duplex Printing	Yes
Fax Modem Speed	33.6 kbps
Functions	Print, Copy, Scan, Fax
Standard Paper Capacity	250 sheets
Mobile Printing	Yes
Max Print Resolution	6000 x 1200 dpi
Scanner Type	Flatbed + ADF
Max Scan Resolution	1200 x 2400 dpi
Connectivity	USB, Ethernet, Wi-Fi
Automatic Document Feeder (ADF)	Yes
Ink Cartridges	Black, Cyan, Magenta, Yellow
Print Speed (Black)	Up to 35 ppm (draft), 12 ppm (ISO)
Print Speed (Color)	27 ppm
Display	2.7" Touchscreen Color LCD
