5. Dial Pad
• Use to dial fax and telephone numbers.
• Use as a keyboard to enter text or characters.
6.
Stop/Exit
• Press to stop an operation.
• Press to exit from a menu.
7.
Power On/Off
Press to turn on the machine.
Press and hold down to turn off the machine. The LCD will display [Shutting Down] and will stay on
for a few seconds before turning itself off. If you have connected an external telephone or TAD, it is always
available.
If you turn off the machine using
, it will still clean the print head periodically to maintain print quality. To
prolong print head life, provide better ink efficiency, and maintain print quality, keep your machine connected
to a power source at all times.
8. Start buttons
Black Start
• Press to start sending faxes in black & white.
• Press to start making copies in black & white.
• Press to start scanning documents (in color or black & white depending on the scan setting).
Color Start
• Press to start sending faxes in full color.
• Press to start making copies in full color.
• Press to start scanning documents (in color or black & white depending on the scan setting).
MFC-J680DW
1. 2.7" Touchscreen Liquid Crystal Display (LCD)
Access menus and options by pressing them on this Touchscreen.
Adjust the angle of the Touchscreen LCD and Touchpanel by lifting it.
11
