CHAPTER 4 DISASSEMBLY AND RE-ASSEMBLY
4-84
3.31 Thermistor ASSY
(1) Remove the thermistor ASSY.
Fig. 4-150
3.32 Fan Motor 60 Unit LV / Fan Motor 60 Unit
(1) Remove the fan motor 60 unit LV and the fan motor 60 unit.
Fig. 4-151
Main frame R
Fan motor 60 unit
Fan motor 60 unit LV
Thermistor ASSY
Frame L
