MFC-8440/8840D/8840DN, DCP-8040/8045D/8045DN
SERVICE MANUAL
4-3
3. DISASSEMBLY PROCEDURE
3.1 AC Cord
(1) Disconnect the AC cord from the machine.
Fig. 4-1
3.2 Drum Unit
(1) Open the front cover and remove the drum unit.
Fig. 4-2
A
C cord
Machine
Drum unit
Front cover
