MFC-8440/8840D/8840DN, DCP-8040/8045D/8045DN
SERVICE MANUAL
A-23
WSW16 (Function setting 1)
Selector
No.
Function Setting and Specifications
1 Not used.
2 CCITT superfine recommendation 0: OFF 1: ON
3
|
6
Not used.
7 Max. document length limitation 0: 400 cm 1: 90 cm
8 Stop button pressed during
reception
0: Not functional 1: Functional
l
Selector 2: CCITT superfine recommendation
If this selector is set to "1," the machine communicates in CCITT recommended superfine
mode (15.4 lines/mm). If it is set to "0," it communicates in native superfine mode.
l Selector 7: Max. document length limitation
This selector is used to select the maximum length of a document to be sent.
l Selector 8: Stop key pressed during reception
If this selector is set to "1," pressing the Stop button can stop the current receiving operation.
The received data will be lost.
