MFC-8440/8840D/8840DN, DCP-8040/8045D/8045DN
SERVICE MANUAL
4-17
3.5 Access Cover / Battery
(1) Remove the access cover.
(2) Loosen the two access plate screws.
(3) Remove the access plate.
Fig. 4-27
(4) Disconnect the connector, and then remove the battery. (MFC-8440/8840D/8840DN only)
!
CAUTION:
• There is a danger of explosion if the battery is incorrectly replaced.
• Use Brother genuine spare part when you replace the battery.
• Do not disassemble, recharge or dispose of in fire.
• Used battery should be disposed of according to local regulations.
Fig. 4-28
A
ccess cove
r
Hooks
Hooks
Hooks
Hooks
A
ccess plate
A
ccess plate screw
A
ccess plate
screw
Battery
Main PCB
