BRP-Rotax
MAINTENANCE MANUAL LINE
SERVICING POINTS ON THE ENGINE
Overview
AE_912_0086
2
4
1
5
6
3
Figure 6.1
1
Expansion tank
2
Radiator cap
3 Oil filter 4 Oil tank
5
Oil tank cover, without venting
6
Oil dipstick
12–10–00
Page 2
January 01 2020
Effectivity: 912 Series
Rev. 0
