BRP ROTAX 912 Series User Manual

BRP-Rotax
MAINTENANCE MANUAL LINE
DIFFERENTIAL PRESSURE CHECK
General note
m WARNING
Risk of electric shock!
Ignition “OFF” and system grounded!
Figure 7.2: Differential pressure check. TYPICAL
1
Adaptor
2
Manometer/Test gauges set
3
Orifice jet
4
Compressor
Special tools To measure the differential pressure the following special tools and equipment are
necessary.
Part number Description
n.a.
Compressed air approx. 6 bar (80 psi).
n.a
2 pressure gauges.
Effectivity: 912 Series
Rev. 0
12–20–00
Page 7
January 01 2020
