BRP ROTAX 912 Series - Lubrication

BRP-Rotax
MAINTENANCE MANUAL LINE
LUBRICATION
Overview
IN
O
U
T
return from engine
to oil pump
08238
Figure 7.24
Figure 7.25
1 Oil tank 2 Drain screw M12x12
3 Oil radiator 4 Oil filter
12–20–00
Page 40
January 01 2020
Effectivity: 912 Series
Rev. 0
