MAINTENANCE MANUAL LINE
CHECK OF WIRING
General note
m WARNING
Risk of electric shock!
Ignition “OFF” and system grounded! Disconnect negative terminal of battery.
m WARNING
Risk of burns and scalds. Hot engine parts.
Always allow engine to cool down to ambient temperature before starting work.
Procedure The following steps have to be carried out:
Step
Procedure
1 Inspect all cable connectors and their connections for tight fit, good contact,
corrosion or damage and replace as necessary.
2
Inspect all ground connections for corrosion and damage, replace if
necessary.
3 Inspect plug connections between pick-up cable, electronic module, charg-
ing and shorting cables for corrosion or damage and replace as required.
4
Inspect plug connections between electronic module and ignition coils for
corrosion or damage and replace if necessary.
5
Verify plug connections on internal generator cables with rectifier-regulator
and connections of all cables on rectifier-regulator for good contact, tight fit,
corrosion, discoloration or damage and replace if necessary.
6
Inspect grounding cables for tight fit, corrosion or damage and replace if
necessary.
7
Verify shielding of cable assemblies for corrosion or damage, good ground
contact and tight fit, inspect the attachment of the shielding and replace if
necessary.
8
Inspect all 8 ignition cables to spark plug connector for corrosion or damage
and tight fit and replace if necessary.
12–20–00
Page 56
January 01 2020
Effectivity: 912 Series
Rev. 0
