BRP ROTAX 912 Series User Manual

BRP-Rotax
MAINTENANCE MANUAL LINE
ATTENTION
An idle speed which is too low can result in gearbox wear, and if the idle speed is
too high, the engine is harder to start.
Step
Procedure
4
Start the engine and verify the idle speed. If the idle speed is too high or too
low, adjust accordingly with idle speed adjustment screw.
5
Check the true running of the engine. If necessary, adjust with the idle mix-
ture screw.
Carry out the above procedure on both carburetors.
X
AE_912_0084
2
4
3
5
1
7
8
6
Figure 7.16: Mechanical synchronization
1 Throttle valve lever 2
Adjustment screw
3
Idle stop position
4 Cable fixation
5
Return spring
6 Idle mixture screw
7
Idle adjustment
8
Plug screw M3.5x5
PNEUMATIC SYNCHRONIZATION
General note
m WARNING
Non-compliance can result in serious injuries or death!
Always observe the engine from a safe place while it is running. Check that the cockpit
is occupied by a competent operator.
Effectivity: 912 Series
Rev. 0
12–20–00
Page 27
January 01 2020
