6. Remove the pump hoses (Fig. 38/1).
7. Clean the pump hoses using the cleaning brush. In case of
severe contamination or wear, replace the pump hoses
(order no. 1529).
8. Reattach the pump hoses.
Ensure that the pump hoses fit securely. Other-
wise water could leak out.
9. Clean the pump body (Fig. 40/1) using a cloth.
10. Clean the electrode rods for measuring the water level
(Fig. 41/1). Depending on the level of contamination, use a
sponge or fine-grit sand paper.
11. To avoid lime remover residues in the device, flush the water
tank thoroughly with tap water.
12. Place the center piece back into the water tank and replace
the cover.
Fig. 38: Removing the pump hoses
Fig. 39: Cleaning the pump hoses
Fig. 40: Cleaning the pump body
Fig. 41: Cleaning the copper elec-
trodes
Cleaning and servicing the humidifier
Evaporation Humidifier B500 Professional 47
