Personnel:
n
Operator
WARNING!
Risk of electrical shock if the power plug is not
disconnected!
1. Switch off the humidifier and disconnect the power plug.
2. To collect any possible residual water, place a suitable con-
tainer under the connection of the water supply.
3. Rotate the safety pressure hose twist-lock located at the
water supply connection (Fig. 80/1) counterclockwise and
remove.
4. Rotate the twist-lock located at the water monitor connection
(Fig. 81/1) counterclockwise and remove.
5. Remove the safety pressure hose.
6. Attach the new safety pressure hose at the water monitor
connection and tighten the twist-lock.
7. Attach the safety pressure hose at the water supply connec-
tion and tighten the twist-lock.
Fig. 80: Removing the safety pressure
hose from the humidifier
Fig. 81: Removing the safety pressure
hose from the water monitor
Accessories
Evaporation Humidifier B500 Professional 75
