Brusa BDC546 - Electrical Interfaces; Control Connector

Technical data
and start-up
BDC546
34
7 Electrical interfaces
1. Control connector
Chapter 7.1Control connector pin assignment
(device side)(device side)
2. Grounding connection
Chapter 7.2 Earthing / grounding screw
(equipotential bonding)
3. Highside plus
Chapter 7.3 Highside and lowside power
connections
4. Highside minus
Chapter 7.3 Highside and lowside power
connections
5. Lowside plus
Chapter 7.3 Highside and lowside power
connections
6. Lowside minus
Chapter 7.3 Highside and lowside power
connections
